Onkyo HT-R380 Service Manual

C6042 CERA C CC45CH50V-030D 1 345340302T
C6043 CERA C CC45CH50V-030D 1 345340302T
C6044 CERA C CC45CH50V-030D 1 345340302T
C6047 CERA C CC45CH50V-030D 1 345340302T
C6050 C-CERA C CK725B1H-472K1 1 332104725R1
C6051 C-CERA C CK725B1H-472K1 1 332104725R1
C6052 C-CERA C CK725B1H-472K1 1 332104725R1
C6053 C-CERA C CK725B1H-472K1 1 332104725R1
C6054 C-CERA C CK725B1H-472K1 1 332104725R1
C6057 C-CERA C CK725B1H-472K1 1 332104725R1
C6060 TF C ECQ-V50V-473J 1 374724734T
C6061 TF C ECQ-V50V-473J 1 374724734T
C6062 TF C ECQ-V50V-473J 1 374724734T
C6063 TF C ECQ-V50V-473J 1 374724734T
C6064 TF C ECQ-V50V-473J 1 374724734T
C6067 TF C ECQ-V50V-473J 1 374724734T
C6070 TF C ECQ-V50V-103J 1 374721034T
C6071 TF C ECQ-V50V-103J 1 374721034T
C6072 TF C ECQ-V50V-103J 1 374721034T
C6073 TF C ECQ-V50V-103J 1 374721034T
C6074 TF C ECQ-V50V-103J 1 374721034T
C6077 TF C ECQ-V50V-103J 1 374721034T
C6080 MKT C B32529C0102J289 1 376491024T <MDC>
C6080 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6081 MKT C B32529C0102J289 1 376491024T <MDC>
C6081 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6082 MKT C B32529C0102J289 1 376491024T <MDC>
C6082 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6083 MKT C B32529C0102J289 1 376491024T <MDC>
C6083 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6084 MKT C B32529C0102J289 1 376491024T <MDC>
C6084 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6087 MKT C B32529C0102J289 1 376491024T <MDC>
C6087 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6088 MKT C B32529C0102J289 1 376491024T <MDC>
C6088 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6089 MKT C B32529C0102J289 1 376491024T <MDC>
C6089 MKT C B32529C0472J289 1 376494724T <MPP, MMO, MMQ>
C6090 UTSP C CE04W25V-100M(UTSP) 1 397551017T
C6091 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C6092 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C6093 C-CERA C CK725F1E-104Z1 1 NSP

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
