Onkyo HT-R380 Service Manual

C6094 C-CERA C CK725F1E-104Z1 1 NSP
C6101 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6102 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6103 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C6104 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6105 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6106 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C6107 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6108 UTSP C CE04W63V-100M(UTSP) 1 397571017T
C6111 TF C ECQ-V50V-103J 1 374721034T
C6112 TF C ECQ-V50V-103J 1 374721034T
C6113 TF C ECQ-V50V-103J 1 374721034T
C6115 TF C ECQ-V50V-103J 1 374721034T
C6117 TF C ECQ-V50V-103J 1 374721034T
C6706 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C6901 ELECT C CE69W56V-8200MB 1 3504416 <MDC, MPB, MPP>
C6901 ELECT C CE69W63V-8200MB 1 3504420 <MMO, MMQ>
C6902 ELECT C CE69W56V-8200MB 1 3504416 <MDC, MPB, MPP>
C6902 ELECT C CE69W63V-8200MB 1 3504420 <MMO, MMQ>
C6911 C-CERA C CC725CH1H-102J1 1 342101024R1
C6912 TF C ECQ-V50V-334J 1 374723344T
C6913 TF C ECQ-V50V-334J 1 374723344T
C950 TF C ECQ-V50V-104J 1 374721044T
C960 VR C CE04W63V-220M(VR) 1 394672217T
C961 VR C CE04W50V-47M(VR) 1 394684707T
C962 C-CERA C CK725F1E-104Z1 1 332161040R1
[RESISTOR]
R4000 C-CARBON R RN72K1J-331JE 1 NSP
R4001 METAL O R RS1WBJ-10 1 443621004T
R4003 C-CARBON R RN72K1J-331JE 1 NSP
R4004 C-CARBON R RN72K1J-331JE 1 NSP
R4005 METAL O R RS1WBJ-15 1 443621504T
R4007 C-CARBON R RN72K1J-331JE 1 NSP
R4008 C-CARBON R RN72K1J-331JE 1 NSP
R4013 C-CARBON R RN72K1J-331JE 1 NSP
R4014 C-CARBON R RN72K1J-331JE 1 NSP
R4015 C-CARBON R RN72K1J-222JE 1 NSP
R4016 C-CARBON R RN72K1J-222JE 1 NSP
R4017 C-CARBON R RN72K1J-331JE 1 NSP
R4020 C-CARBON R RN72K1J-331JE 1 NSP
R4023 C-CARBON R RN72K1J-000JE 1 NSP
R4043 C-CARBON R RN72K1J-104JE 1 NSP

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
