Onkyo HT-R490 User Manual

33
CODE LIST
Brand TV VCR CABLE DVD SAT
ADMIRAL 01-03 01 ———
AIWA — 02 ———
AOC 04 ————
AUDIO DYNAMIC — 03, 04 ———
BELL & HOWELL 01, 02 05 ———
BROKSONIC 04 06, 07 ———
CANON — 08, 09 ———
CITIZEN — 10 ———
CRAIG 05-08 10 ———
CROSLEX 09 ————
CURTIS MATHIS 04, 08, 10 02, 09, 11 ———
DAEWOO 04, 11, 12 09, 12, 13 ———
DAYTRON 13 ————
DBX — 03, 04, 14 ———
DENON ———04, 05 —
DIMENSIA — 11 ———
ECHOSTAR ————01
EMERSON 04-08, 13, 14 06, 07, 13, 15-17 ———
FISHER 15 05, 18-20 ———
FUNAI — 02 ———
GE 03, 04, 16-18 09, 11, 21 ———
GENERAL INSTRUMENT ——06-13 — 02
GOLDSTAR 04, 13, 19 10 ———
HAMLIN ——01-05 ——
HITACHI 04, 13, 20, 21 08, 11, 22 ——07
INSTANT REPLAY — 08, 09 ———
JC PENNEY 03, 04, 17, 19 03-05, 09, 11, 22 ———
JERROLD ——06-13 — 02
JVC 22 03, 04 — 06 01
KENWOOD — 03, 04, 10 ———
KTV 04, 08, 13 ————
LXI 03, 09, 10, 15 02, 05, 10, 18-20, 22 ———
MAGNAVOX 04, 09, 13 08, 09, 23 ——08
MARANTZ — 03, 04
MARTA — 10 ———
MEMOREX — 09, 20 ———
MINOLTA — 11, 22 ———
MITSUBISHI 04, 23 24-27 ———
MULTITECH — 02, 26, 28 ———
NEC 04 03, 04 ——03, 04
OAK ——14-16 ——
OLYMPIC — 08, 09 ———
ONKYO ———01-03 —
PANASONIC 16-18, 24 08, 09, 29 17-19 05, 07 09
PENTAX — 11, 22 ———
PHILCO 04, 09, 13 08, 09 ———
PHILIPS 09 08, 09, 23 ———
PIONEER 10, 18, 25 08 20, 21 08-10 —
PORTLAND 04, 26 ————
PRIMESTAR ————02
PROSCAN 03 08, 09, 11, 12, ———
22, 23, 30, 31
QUASAR 17, 18 08, 09 ———
RADIO SHACK 03, 04, 08, 23 ———10
RCA 03, 04, 17, 26-28 08, 09, 11, 12, — 11 05
22, 23, 30, 31
REALISTIC — 02, 05, 09, 20, 25, 32 ———
SAMSUNG 04, 13, 29 28, 31, 33 — 12 —
SANSUI — 03 ———
SANYO 15 05, 20 ———
SCIENTIFIC ATLANTA ——22-24 ——
SCOTT 04, 08 12, 20, 24-28, 31 ———
SHARP 02, 13, 14 01, 32 ———
SIGNATURE 2000 01, 02 01, 02 ———
SONY 30 34-36 — 13 06
SYLVANIA 04, 09 02, 08, 09, 23 ———
SYMPHONIC 08 02 ———
TASHIRO — 10 ———
TATUNG — 03, 04 ———
TEAC — 02-04 ———
TECHNICS — 08, 09 ———
TOCOM ——25 ——
TOSHIBA 02, 10 12, 30 — 14 11
UNIDEN ————08
VIDTECH 04, 20 ————
WARDS 04, 13, 14 01, 10, 20, 32, 37 ———
YAMAHA 02, 23 03-05, 24 — 05, 15 —
ZENITH 01, 31 37 26, 27 — 12
Pre-programming remote controller

Onkyo HT-R490 Specifications

Amplifier Section

continuous average power output (FTC) - 8 ohms	55 watts per channel min. RMS
continuous average power output (FTC) - 6 ohms	70 watts min. RMS
continuous power output (DIN)	75 watts × 5 at 6 ohms
maximum power output (EIAJ)	100 watts × 5 at 6 ohms
total harmonic distortion	0.08% at rated power (Front)
IM distortion	0.08% at rated power (Front)
damping factor	60 at 8 ohms (Front)
input sensitivity and impedance - LINE	200 mV, 50 kohms
input sensitivity and impedance - MULTICHANNEL INPUT (FRONT L/R, SURROUND L/R, CENTER)	200 mV, 50 kohms
input sensitivity and impedance - MULTICHANNEL INPUT (SUBWOOFER)	36 mV, 50 kohms
input sensitivity and impedance - DIGITAL 2 (COAXIAL)	0.5 Vp-p, 75 ohms
output level and impedance - Rec out (TAPE, VIDEO 2)	200 mV, 2.2 kohms
output level and impedance - Pre out (SUBWOOFER)	1 V, 2.2 kohms
frequency response	20 Hz to 100 kHz, +1/–3 dB
RIAA deviation	20 Hz to 20 kHz, ±0.8 dB
tone control - Bass	±10 dB at 50 Hz
tone control - Treble	±10 dB at 10 kHz
signal-to-noise ratio - CD/Tape	100 dB (IHF-A)

Tuner Section

FM tuning range	87.5-108.0 MHz (50 kHz steps)
FM usable sensitivity - Mono	11.2 dBf, 1.0 µV (75 ohms)
FM usable sensitivity - Stereo	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB quieting sensitivity - Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB quieting sensitivity - Stereo	37.2 dBf, 2.0 µV (75 ohms)
FM capture ratio	2.0 dB
FM image rejection ratio	40 dB
FM IF rejection ratio	90 dB
FM signal-to-noise ratio - Mono	76 dB
FM signal-to-noise ratio - Stereo	70 dB
FM alternate channel attenuation	55 dB
FM selectivity	50 dB (DIN)
FM AM suppression ratio	50 dB
FM total harmonic distortion - Mono	0.2%
FM total harmonic distortion - Stereo	0.3%
FM frequency response	30 Hz-15 kHz, ±1.0 dB
FM stereo separation	45 dB at 1 kHz
AM tuning range	530-1, 710 kHz (10 kHz steps)
AM usable sensitivity	30 µV
AM image rejection ratio	40 dB
AM IF rejection ratio	40 dB
AM signal-to-noise ratio	40 dB
AM total harmonic distortion	0.7%

General

power supply	AC 120 V, 60 Hz
power consumption	3.4 A
dimensions (W × H × D)	435 × 150 × 339 mm
weight	9.7 kg, 21.4 lbs.
