Onkyo HT-R520 Service Manual

20/40 PAGE
PCB
JL7502B WIRE HOL NSCT-5P896 1 25051109
U06 DRIVER AMPLIFIER PC BOARD (NAAF-8235-1A/1B/1D)
U07 COMPONENT VIDEO TERMINAL PC BOARD (NAVD-8236-1A/1B/1D)
U09 REGULATOR PC BOARD (NAETC-8238-1A/1B/1D)
U10 TERMINAL PC BOARD (NAETC-8239-1A/1B/1D)
U11 SPEAKER TERMINAL PC BOARD (NAETC-8240-1D)
U12 HOLDER PC BOARD (NAETC-8241-1A/1B/1D)
U14 TERMINAL PC BOARD (NAETC-8243-1A/1B/1D)
U15 SPEAKER TERMINAL PC BOARD (NAETC-8244-1A/1B/1D)
<Notes> Parts are indicated collectively, without dividing for above-mentioned each substrate.
<Notes>
<502>:TX-SR502 <DC> : Canadian model
<502E>:TX-SR502E(European model) <DD> : American model
<8250>:TX-SR8250(Chinese model) <GK> : Korean model
<520>:HT-R520(American model & Canadian model) <GQ> : Hong kong model
<GR> : Chinese model
<PA> : Australian model
<PT> : Asian model (230-240V)
<WT> : World wide model
REF. NO. NAME DESCRIPTION Q'TY PART NO
REMARKS
PCB
Q241 TR KTC3199-GR 1 2215864
PCB
Q241 or TR 2SC1740S-R ( 1) 2213284
PCB
Q241 or TR 2SC1740S-S ( 1) 2213285
PCB
Q241 or TR 2SC2458-GR ( 1) 2212115
PCB
Q5000 TR KTC3200-BL 1 2215896
PCB
Q5000 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5000 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5000 or TR 2SC1845-E ( 1) 2211733
PCB
Q5001 TR KTC3200-BL 1 2215896
PCB
Q5001 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5001 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5001 or TR 2SC1845-E ( 1) 2211733
PCB
Q5002 TR KTC3200-BL 1 2215896
PCB
Q5002 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5002 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5002 or TR 2SC1845-E ( 1) 2211733
PCB
Q5003 TR KTC3200-BL 1 2215896
PCB
Q5003 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5003 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5003 or TR 2SC1845-E ( 1) 2211733
PCB
Q5004 TR KTC3200-BL 1 2215896
PCB
Q5004 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5004 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5004 or TR 2SC1845-E ( 1) 2211733
PCB
Q5005 TR KTC3200-BL 1 2215896
PCB
Q5005 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5005 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5005 or TR 2SC1845-E ( 1) 2211733
PCB
Q5010 TR KTC3200-BL 1 2215896
PCB
Q5010 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5010 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5010 or TR 2SC1845-E ( 1) 2211733
PCB
Q5011 TR KTC3200-BL 1 2215896
PCB
Q5011 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5011 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5011 or TR 2SC1845-E ( 1) 2211733
PCB
Q5012 TR KTC3200-BL 1 2215896
PCB
Q5012 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5012 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5012 or TR 2SC1845-E ( 1) 2211733
PCB
Q5013 TR KTC3200-BL 1 2215896
PCB
Q5013 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5013 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5013 or TR 2SC1845-E ( 1) 2211733
PCB
Q5014 TR KTC3200-BL 1 2215896
PCB
Q5014 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5014 or TR 2SC1775A-F ( 1) 2210756
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
