Onkyo HT-R520 Service Manual

21/40 PAGE
PCB
Q5014 or TR 2SC1845-E ( 1) 2211733
PCB
Q5015 TR KTC3200-BL 1 2215896
PCB
Q5015 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5015 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5015 or TR 2SC1845-E ( 1) 2211733
PCB
Q5030 TR KTA1024-Y 1 2215844
<502>,<502E>,<8250>
PCB
Q5030 or TR KTA1024-O ( 1) 2215843
<502>,<502E>,<8250>
PCB
Q5030 or TR 2SA949-O ( 1) 2211353
<502>,<502E>,<8250>
PCB
Q5030 or TR 2SA949-Y ( 1) 2211354
<502>,<502E>,<8250>
PCB
Q5030 TR 2SA949-Y(ONK) 1 2211359
<520>
PCB
Q5030 or TR 2SA949-O(ONK) ( 1) 2211358
<520>
PCB
Q5031 TR KTA1024-Y 1 2215844
<502>,<502E>,<8250>
PCB
Q5031 or TR KTA1024-O ( 1) 2215843
<502>,<502E>,<8250>
PCB
Q5031 or TR 2SA949-Y ( 1) 2211354
<502>,<502E>,<8250>
PCB
Q5031 or TR 2SA949-O ( 1) 2211353
<502>,<502E>,<8250>
PCB
Q5031 TR 2SA949-Y(ONK) 1 2211359
<520>
PCB
Q5031 or TR 2SA949-O(ONK) ( 1) 2211358
<520>
PCB
Q5032 TR KTA1024-Y 1 2215844
<502>,<502E>,<8250>
PCB
Q5032 or TR KTA1024-O ( 1) 2215843
<502>,<502E>,<8250>
PCB
Q5032 or TR 2SA949-O ( 1) 2211353
<502>,<502E>,<8250>
PCB
Q5032 or TR 2SA949-Y ( 1) 2211354
<502>,<502E><8250>
PCB
Q5032 TR 2SA949-Y(ONK) 1 2211359
<520>
PCB
Q5032 or TR 2SA949-O(ONK) ( 1) 2211358
<520>
PCB
Q5033 TR KTA1024-Y 1 2215844
<502>,<502E>,<8250>
PCB
Q5033 or TR KTA1024-O ( 1) 2215843
<502>,<502E>,<8250>
PCB
Q5033 or TR 2SA949-Y ( 1) 2211354
<502>,<502E>,<8250>
PCB
Q5033 or TR 2SA949-O ( 1) 2211353
<502>,<502E>,<8250>
PCB
Q5033 TR 2SA949-Y(ONK) 1 2211359
<520>
PCB
Q5033 or TR 2SA949-O(ONK) ( 1) 2211358
<520>
PCB
Q5034 TR KTA1024-Y 1 2215844
<502>,<502E>,<8250>
PCB
Q5034 or TR KTA1024-O ( 1) 2215843
<502>,<502E>,<8250>
PCB
Q5034 or TR 2SA949-Y ( 1) 2211354
<502>,<502E>,<8250>
PCB
Q5034 or TR 2SA949-O ( 1) 2211353
<502>,<502E>,<8250>
PCB
Q5034 TR 2SA949-Y(ONK) 1 2211359
<520>
PCB
Q5034 or TR 2SA949-O(ONK) ( 1) 2211358
<520>
PCB
Q5035 TR KTA1024-Y 1 2215844
<502>,<502E>,<8250>
PCB
Q5035 or TR KTA1024-O ( 1) 2215843
<502>,<502E>,<8250>
PCB
Q5035 or TR 2SA949-Y ( 1) 2211354
<502>,<502E>,<8250>
PCB
Q5035 or TR 2SA949-O ( 1) 2211353
<502>,<502E>,<8250>
PCB
Q5035 TR 2SA949-Y(ONK) 1 2211359
<520>
PCB
Q5035 or TR 2SA949-O(ONK) ( 1) 2211358
<520>
PCB
Q5040 TR KTC3206-Y 1 2215854
<502>,<502E>,<8250>
PCB
Q5040 or TR KTC3206-O ( 1) 2215853
<502><502E>,<8250>
PCB
Q5040 or TR 2SC2229-Y ( 1) 2211634
<502>,<502E>,<8250>
PCB
Q5040 or TR 2SC2229-O ( 1) 2211633
<502>,<502E>,<8250>
PCB
Q5040 TR 2SC2229-Y(ONK) 1 2211639
<520>
PCB
Q5040 or TR 2SC2229-O(ONK) ( 1) 2211638
<520>
PCB
Q5041 TR KTC3206-Y 1 2215854
<502>,<502E>,<8250>
PCB
Q5041 or TR KTC3206-O ( 1) 2215853
<502>,<502E>,<8250>
PCB
Q5041 or TR 2SC2229-Y ( 1) 2211634
<502>,<502E>,<8250>
PCB
Q5041 or TR 2SC2229-O ( 1) 2211633
<502>,<502E>,<8250>
PCB
Q5041 TR 2SC2229-Y(ONK) 1 2211639
<520>
PCB
Q5041 or TR 2SC2229-O(ONK) ( 1) 2211638
<520>
PCB
Q5042 TR KTC3206-Y 1 2215854
<502>,<502E>,<8250>
PCB
Q5042 or TR KTC3206-O ( 1) 2215853
<502>,<502E>,<8250>
PCB
Q5042 or TR 2SC2229-Y ( 1) 2211634
<502>,<502E>,<8250>
PCB
Q5042 or TR 2SC2229-O ( 1) 2211633
<502>,<502E>,<8250>
PCB
Q5042 TR 2SC2229-Y(ONK) 1 2211639
<520>
PCB
Q5042 or TR 2SC2229-O(ONK) ( 1) 2211638
<520>
PCB
Q5043 TR KTC3206-Y 1 2215854
<502>,<502E>,<8250>
PCB
Q5043 or TR KTC3206-O ( 1) 2215853
<502>,<502E>,<8250>
PCB
Q5043 or TR 2SC2229-Y ( 1) 2211634
<502>,<502E>,<8250>
PCB
Q5043 or TR 2SC2229-O ( 1) 2211633
<502>,<502E>,<8250>
PCB
Q5043 TR 2SC2229-Y(ONK) 1 2211639
<520>
PCB
Q5043 or TR 2SC2229-O(ONK) ( 1) 2211638
<520>
PCB
Q5044 TR KTC3206-Y 1 2215854
<502>,<502E>,<8250>
PCB
Q5044 or TR KTC3206-O ( 1) 2215853
<502>,<,502E>,<8250>
PCB
Q5044 or TR 2SC2229-Y ( 1) 2211634
<502>,<502E>,<8250>
PCB
Q5044 or TR 2SC2229-O ( 1) 2211633
<502>,<502E>,<8250>
PCB
Q5044 TR 2SC2229-Y(ONK) 1 2211639
<520>
PCB
Q5044 or TR 2SC2229-O(ONK) ( 1) 2211638
<520>
PCB
Q5045 TR KTC3206-Y 1 2215854
<502>,<502E>,<8250>
PCB
Q5045 or TR KTC3206-O ( 1) 2215853
<502>,<502E>,<8250>
