Onkyo HT-R520 Service Manual

22/40 PAGE
PCB
Q5045 or TR 2SC2229-Y ( 1) 2211634
<502>,<502E>,<8250>
PCB
Q5045 or TR 2SC2229-O ( 1) 2211633
<502>,<502E>,<8250>
PCB
Q5045 TR 2SC2229-Y(ONK) 1 2211639
<520>
PCB
Q5045 or TR 2SC2229-O(ONK) ( 1) 2211638
<520>
PCB
Q5050 TR KTC3199-GR 1 2215864
<502>,<502E>,<8250>
PCB
Q5050 or TR 2SC1740S-R ( 1) 2213284
<502>,<502E>,<8250>
PCB
Q5050 or TR 2SC1740S-S ( 1) 2213285
<502>,<502E>,<8250>
PCB
Q5050 or TR 2SC2458-GR ( 1) 2212115
<502>,<502E>,<8250>
PCB
Q5050 TR KTC3200-BL 1 2215896
<520>
PCB
Q5050 or TR KTC3200-GR ( 1) 2215895
<520>
PCB
Q5050 or TR 2SC1775A-E ( 1) 2210755
<520>
PCB
Q5050 or TR 2SC1775A-F ( 1) 2210756
<520>
PCB
Q5050 or TR 2SC1845-E ( 1) 2211733
<520>
PCB
Q5050 or TR 2SC1845-F ( 1) 2211732
<520>
PCB
Q5051 TR KTC3199-GR 1 2215864
<502>,<502E>,<8250>
PCB
Q5051 or TR 2SC1740S-R ( 1) 2213284
<502>,<502E>,<8250>
PCB
Q5051 or TR 2SC1740S-S ( 1) 2213285
<502>,<502E>,<8250>
PCB
Q5051 or TR 2SC2458-GR ( 1) 2212115
<502>,<502E>,<8250>
PCB
Q5051 TR KTC3200-BL 1 2215896
<520>
PCB
Q5051 or TR KTC3200-GR ( 1) 2215895
<520>
PCB
Q5051 or TR 2SC1775A-E ( 1) 2210755
<520>
PCB
Q5051 or TR 2SC1775A-F ( 1) 2210756
<520>
PCB
Q5051 or TR 2SC1845-E ( 1) 2211733
<520>
PCB
Q5051 or TR 2SC1845-F ( 1) 2211732
<520>
PCB
Q5052 TR KTC3199-GR 1 2215864
<502>,<502E><8250>
PCB
Q5052 or TR 2SC1740S-R ( 1) 2213284
<502>,<502E>,<8250>
PCB
Q5052 or TR 2SC1740S-S ( 1) 2213285
<502>,<502E>,<8250>
PCB
Q5052 or TR 2SC2458-GR ( 1) 2212115
<502>,<502E>,<8250>
PCB
Q5052 TR KTC3200-BL 1 2215896
<520>
PCB
Q5052 or TR KTC3200-GR ( 1) 2215895
<520>
PCB
Q5052 or TR 2SC1775A-E ( 1) 2210755
<520>
PCB
Q5052 or TR 2SC1775A-F ( 1) 2210756
<520>
PCB
Q5052 or TR 2SC1845-E ( 1) 2211733
<520>
PCB
Q5052 or TR 2SC1845-F ( 1) 2211732
<520>
PCB
Q5053 TR KTC3199-GR 1 2215864
<502>,<502E>,<8250>
PCB
Q5053 or TR 2SC1740S-R ( 1) 2213284
<502>,<502E>,<8250>
PCB
Q5053 or TR 2SC1740S-S ( 1) 2213285
<502>,<502E>,<8250>
PCB
Q5053 or TR 2SC2458-GR ( 1) 2212115
<502>,<502E>,<8250>
PCB
Q5053 TR KTC3200-BL 1 2215896
<520>
PCB
Q5053 or TR KTC3200-GR ( 1) 2215895
<520>
PCB
Q5053 or TR 2SC1775A-E ( 1) 2210755
<520>
PCB
Q5053 or TR 2SC1775A-F ( 1) 2210756
<520>
PCB
Q5053 or TR 2SC1845-E ( 1) 2211733
<520>
PCB
Q5053 or TR 2SC1845-F ( 1) 2211732
<520>
PCB
Q5054 TR KTC3199-GR 1 2215864
<502><502E>,<8250>
PCB
Q5054 or TR 2SC1740S-R ( 1) 2213284
<502>,<502E>,<8250>
PCB
Q5054 or TR 2SC1740S-S ( 1) 2213285
<502>,<502E>,<8250>
PCB
Q5054 or TR 2SC2458-GR ( 1) 2212115
<502>,<502E>,<8250>
PCB
Q5054 TR KTC3200-BL 1 2215896
<520>
PCB
Q5054 or TR KTC3200-GR ( 1) 2215895
<520>
PCB
Q5054 or TR 2SC1775A-E ( 1) 2210755
<520>
PCB
Q5054 or TR 2SC1775A-F ( 1) 2210756
<520>
PCB
Q5054 or TR 2SC1845-E ( 1) 2211733
<520>
PCB
Q5054 or TR 2SC1845-F ( 1) 2211732
<520>
PCB
Q5055 TR KTC3199-GR 1 2215864
<502>,<502E>,<8250>
PCB
Q5055 or TR 2SC1740S-R ( 1) 2213284
<502>,<502E>,<8250>
PCB
Q5055 or TR 2SC1740S-S ( 1) 2213285
<502>,<502E>,<8250>
PCB
Q5055 or TR 2SC2458-GR ( 1) 2212115
<502>,<502E>,<8250>
PCB
Q5055 TR KTC3200-BL 1 2215896
<520>
PCB
Q5055 or TR KTC3200-GR ( 1) 2215895
<520>
PCB
Q5055 or TR 2SC1775A-E ( 1) 2210755
<520>
PCB
Q5055 or TR 2SC1775A-F ( 1) 2210756
<520>
PCB
Q5055 or TR 2SC1845-E ( 1) 2211733
<520>
PCB
Q5055 or TR 2SC1845-F ( 1) 2211732
<520>
PCB
Q6931 IC(REGULATOR) 78M56(NJM78M56FA) 1 222780565JRC
PCB
Q6931 or IC(REGURATOR) 78057HF(TA78057S) ( 1) 222780574TOS
PCB
D241 DIODE 1SS133 1 223163
PCB
D241 or DIODE 1SS270A ( 1) 223205
PCB
D241 or DIODE 1N4148M ( 1) 223273
PCB
D5000 ZENER D MTZJ5.6B 1 224470562
PCB
D5000 or ZENER D DZ-5.6BSB ( 1) 224850562
PCB
D5001 ZENER D MTZJ5.6B 1 224470562
PCB
D5001 or ZENER D DZ-5.6BSB ( 1) 224850562
