Onkyo HT-R520 Service Manual

23/40 PAGE
PCB
D5002 ZENER D MTZJ5.6B 1 224470562
PCB
D5002 or ZENER D DZ-5.6BSB ( 1) 224850562
PCB
D5003 ZENER D MTZJ5.6B 1 224470562
PCB
D5003 or ZENER D DZ-5.6BSB ( 1) 224850562
PCB
D5004 ZENER D MTZJ5.6B 1 224470562
PCB
D5004 or ZENER D DZ-5.6BSB ( 1) 224850562
PCB
D5005 ZENER D MTZJ5.6B 1 224470562
PCB
D5005 or ZENER D DZ-5.6BSB ( 1) 224850562
PCB
D5800 DIODE 1SS133 1 223163
<502>,<502E>,<8250>
PCB
D5800 or DIODE 1SS270A ( 1) 223205
<502>,<502E>,<8250>
PCB
D5800 or DIODE WG713A ( 1) 223222
<502>,<502E>,<8250>
PCB
D5800 or DIODE 1N4148M ( 1) 223273
<502>,<502E>,<8250>
PCB
D5801 DIODE 1SS133 1 223163
<502>,<502E>,<8250>
PCB
D5801 or DIODE 1SS270A ( 1) 223205
<502>,<502E>,<8250>
PCB
D5801 or DIODE WG713A ( 1) 223222
<502>,<502E>,<8250>
PCB
D5801 or DIODE 1N4148M ( 1) 223273
<502>,<502E>,<8250>
PCB
D5804 DIODE 1SS133 1 223163
<502>,<502E>,<8250>
PCB
D5804 or DIODE 1SS270A ( 1) 223205
<502>,<502E>,<8250>
PCB
D5804 or DIODE WG713A ( 1) 223222
<502>,<502E>,<8250>
PCB
D5804 or DIODE 1N4148M ( 1) 223273
<502>,<502E>,<8250>
PCB
D6800 DIODE 1SS133 1 223163
<502>
PCB
D6800 or DIODE 1SS270A ( 1) 223205
<502>
PCB
D6800 or DIODE WG713A ( 1) 223222
<502>
PCB
D6800 or DIODE 1N4148M ( 1) 223273
<502>
PCB
D6801 DIODE 1SS133 1 223163
<502>
PCB
D6801 or DIODE 1SS270A ( 1) 223205
<502>
PCB
D6801 or DIODE WG713A ( 1) 223222
<502>
PCB
D6801 or DIODE 1N4148M ( 1) 223273
<502>
PCB
D6804 DIODE 1SS133 1 223163
<502>
PCB
D6804 or DIODE 1SS270A ( 1) 223205
<502>
PCB
D6804 or DIODE WG713A ( 1) 223222
<502>
PCB
D6804 or DIODE 1N4148M ( 1) 223273
<502>
PCB
D6932 DIODE RL1N4003 1 22380260
PCB
D6932 or DIODE GP104003E ( 1) 22380035
PCB
D6933 DIODE RL1N4003 1 22380260
PCB
D6933 or DIODE GP104003E ( 1) 22380035
PCB
L5800 S COIL S-1.3C 1 231176S
<502>,<502E>,<8250>
PCB
L5801 S COIL S-1.3C 1 231176S
<502>,<502E>,<8250>
PCB
L5802 S COIL S-1.3C 1 231176S
<502>,<502E>,<8250>
PCB
L5803 S COIL S-1.3C 1 231176S
<502>,<502E>,<8250>
PCB
L5804 S COIL S-1.3C 1 231176S
<502>,<502E>,<8250>
PCB
L5805 S COIL S-1.3C 1 231176S
<502>,<502E>,<8250>
PCB
C241 CERA C CK45F50V-103Z 1 335621030
PCB
C5000 TF C ECQ-B50V-101K 1 374721015
PCB
C5001 TF C ECQ-B50V-101K 1 374721015
PCB
C5002 TF C ECQ-B50V-101K 1 374721015
PCB
C5003 TF C ECQ-B50V-101K 1 374721015
PCB
C5004 TF C ECQ-B50V-101K 1 374721015
PCB
C5005 TF C ECQ-B50V-101K 1 374721015
PCB
C5010 VX C CE04W16V-47M(VX) 1 393344707
PCB
C5011 VX C CE04W16V-47M(VX) 1 393344707
PCB
C5012 VX C CE04W16V-22M(VX) 1 393342207
PCB
C5013 VX C CE04W16V-22M(VX) 1 393342207
PCB
C5014 VX C CE04W16V-22M(VX) 1 393342207
PCB
C5015 VX C CE04W16V-22M(VX) 1 393342207
PCB
C5020 VR C CE04W50V-10M(VR) 1 394681007
PCB
C5021 VR C CE04W50V-10M(VR) 1 394681007
PCB
C5022 VR C CE04W50V-10M(VR) 1 394681007
PCB
C5023 VR C CE04W50V-10M(VR) 1 394681007
PCB
C5024 VR C CE04W50V-10M(VR) 1 394681007
PCB
C5025 VR C CE04W50V-10M(VR) 1 394681007
PCB
C5040 VX C CE04W16V-220M(VX) 1 393342217
PCB
C5041 VX C CE04W16V-220M(VX) 1 393342217
PCB
C5042 VX C CE04W16V-220M(VX) 1 393342217
PCB
C5043 VX C CE04W16V-220M(VX) 1 393342217
PCB
C5044 VX C CE04W16V-220M(VX) 1 393342217
PCB
C5045 VX C CE04W16V-220M(VX) 1 393342217
PCB
C5050 VR C CE04W50V-47M(VR) 1 394684707
PCB
C5051 VR C CE04W50V-47M(VR) 1 394684707
PCB
C5052 VR C CE04W50V-47M(VR) 1 394684707
PCB
C5053 VR C CE04W50V-47M(VR) 1 394684707
PCB
C5054 VR C CE04W50V-47M(VR) 1 394684707
PCB
C5055 VR C CE04W50V-47M(VR) 1 394684707
