HT-RC630 HT-RC630
EXPLODED VIEW
OVERALL
4
8
3
14
3
8
3
6
2.6
8
Unit : mm
3
8
Q6050
Q6051
Q6052
Q6053
Q6054 Q6060
Q6061
Q6062
Q6063
Q6064
A101
P8001
P9001
U0011
U0012
U0030
U0031
U0032
U0040
U0041
U0043
U0044
U0045
U0080
U0090
U0120
U791B
A003
x 4 pcs.
A201
A203
A205
A401
T901
A005
x 4 pcs.
A221
A207
A209
A211
A213
A214
A215
A217
A219
A215
A411
U0120A
U0120B
F6401
F6402
F901
P701
U0013
U0010
U0042
U791C
U791A
U792
FFC
P101
FFC
P8003
FFC
P2800
FFC
P801
Heatsink
Rear Panel
Information to the user.
Indicate "Contains FCC ID: TX2-RTL8723AS", "Contains IC: 6317A- RTL8723AS" and following information to the
host device installed.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Describe the following sentence to a user's manual of the host device.
[For FCC]
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low
levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is
desirable that it should be installed and operated keeping the radiator at least 20cm or more away from person’s
body (excluding extremities: hands, wrists, feet and ankles).
[For IC]
CAN ICES-3 B/NMB-3 B
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets
RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it
deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be
installed and operated keeping the radiator at least 20cm or more away from person’s body (excluding extremities:
hands, wrists, feet and ankles).
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non
contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement
émet une énergie RF très faible qui est considérée conforme sans évaluation de l’exposition maximale
autorisée. Cependant, cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre
le dispositif rayonnant et le corps (à l’exception des extrémités : mains, poignets, pieds et chevilles).
WiFi & Bluetooth Module has already been certificated by FCC and IC.
WiFi & Bluetooth Module
This module transmitter does not have RF shielding,
therefore it will be equipped only the tested Audio system
mentioning this document.
Additional test will be required if it will be equipped to the
other devices
<NOTE>
U791(WIFI MODULE) = U791A + U791B + U791C
4TTC+8C(3BC)SR
x 4 pcs.
3SMS8W.SW+14B(CU)
x 10 pcs.
3TTB+8B(3CM)SR
3P+6FN(3BC)
x 8 pcs.
2.6TTB+8B(3BC)
x 16 pcs.
L-40mm
Except
MDC, MMR
3TTB+8B(BC)
<NOTE>
No description screw is 3TTB+8B(3BC).
