Onkyo HTR-548 SERIES

22/52 PAGE
U002
U002 U0020 + U0021 + U0022 + U0023 + U0024
U002
U0020
Display PC board ass'y BADIS-0654-1D
U002
U0021
Standby switch PC board ass'y BADIS-0655-1D
U002
U0022
Video PC board ass'y BAVD-0656-1D
U002
U0023
HP Jack PC board ass'y BAETC-0658-1D
U002
U0024
Primary Wiring PC board ass'y BAPS-0659-1D
U002
U002
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U002
[SEMI CONDUCTOR]
U002
D7002 ZENER D DZ2J082M0L 1 224760820R2
U002
D7002 or ZENER D UDZS8.2B ( 1) 224550820R2
U002
D7033 ZENER D DZ2J039M0L 1 224760390R2
U002
D7033 or ZENER D UDZS3.9B ( 1) 224550390R2
U002
D7152 LED SLI-343Y8C-TE7 1 225490T
U002
D7301 C-DIODE DA2J10100 1 223303R2 N
U002
D7301 or C-DIODE 1SS352 ( 1) 223234R2
U002
D7301 or C-DIODE 1SS355 ( 1) 223269R2
U002
D7301 or C-DIODE MA2J111 ( 1) 223279R2
U002
D7301 or C-DIODE KDS4148U ( 1) 223283R2
U002
D7302 C-DIODE DA2J10100 1 223303R2 N
U002
D7302 or C-DIODE 1SS352 ( 1) 223234R2
U002
D7302 or C-DIODE 1SS355 ( 1) 223269R2
U002
D7302 or C-DIODE MA2J111 ( 1) 223279R2
U002
D7302 or C-DIODE KDS4148U ( 1) 223283R2
U002
D7401 ZENER D DZ2J051M0L 1 224760510R2
U002
D7401 or ZENER D UDZS5.1B ( 1) 224550510R2
U002
D7411 ZENER D DZ2J068M0L 1 224760680R2
U002
D7411 or ZENER D UDZS6.8B ( 1) 224550680R2
U002
D7412 ZENER D DZ2J068M0L 1 224760680R2
U002
D7412 or ZENER D UDZS6.8B ( 1) 224550680R2
U002
D7501 C-DIODE DA2J10100 1 223303R2
U002
D7501 or C-DIODE 1SS352 ( 1) 223234R2
U002
D7501 or C-DIODE 1SS355 ( 1) 223269R2
U002
D7501 or C-DIODE MA2J111 ( 1) 223279R2
U002
D7501 or C-DIODE KDS4148U ( 1) 223283R2
U002
D7502 C-DIODE DA2J10100 1 223303R2
U002
D7502 or C-DIODE 1SS352 ( 1) 223234R2
U002
D7502 or C-DIODE 1SS355 ( 1) 223269R2
