Onkyo HTR-548 SERIES User Manual

5/52 PAGE
PV
A807 INS MANUAL Ct(HTR548) 1 29400614
N
<MMQ>
PV
A807 INS MANUAL En(HTP-548) 1 29400632
N
<MPP>
PV
A808 INS MANUAL U8(HTP-770) 1 29400119 <MPP>
PV
A809 INS MANUAL Ar(HTR548) 1 29400613
N
<MMQ>
PV
A810 INS MANUAL Ar(QC ImportantSheet) 1 29344373B <MMQ>
PV
A811 INS MANUAL En-QSS(HTS5405) 1 29400609
N
PV
A812 INS MANUAL En(HTP-548) 1 29400632
N
<MMQ>
PV
A813 INS MANUAL U8(HTP-770) 1 29400119 <MMQ>
PV
A818 INS MANUAL ItDe(HTR548) 1 29400611
N
< MPP>
PV
A826 INST SHEET U11(2010_RIHD) 1 29355782
PV
A830 INST SHEET WEEE 1 29355793A <MPP>
PV
A841 INST SHEET (TX-SR309_USB) 1 29355830
N
PV
A843 INST SHEET (TX-SR309_HP) 1 29355831
N
PV
A855 REMO CON RC-799M 1 24140799
PV
A856 MIC MIC-7000 1 245044
PV
A858 ANT COIL NMA-3057 1 232140
PV
A859 FM ANT AS Type W 1 292191
PV
A861 BATTERY R6/AA(UM-3) 2 3010194
PV
A861 or BATTERY R6/AA(UM-3) ( 2) 3010054
PV
A884 WRNTY CARD MGQ 1 29365099A <MMQ>
HT-R548
U001
PC BOARD PARTS LIS
T
U001
U001
U001 U0010 + U0011 + U0012 + U0013 + U0014 + U0015 + U0016
U001
U0010
Power Amp / Audio Input Terminals PC board BAAF-0614-1G/ 1H
U001
U0011
Digital Input Terminals PC board BADG-0615-1G/ 1H
U001
U0012
Thermal Senser PC board BAETC-0616-1G/ 1H
U001
U0013
Spacer PC board BAETC-0617-1G/ 1H
U001
U0014
Terminal PC board BAETC-0618--1G/ 1H
U001
U0015
FFC Fixture PC board BAETC-0619-1G/ 1H
U001
U0016
Power supply PC board BAETC-0620-1G/ 1H
U001
U001
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U001
[SEMI CONDUCTOR]
U001
D131 C-DIODE DA2J10100 1 223303R2 N
U001
D131 or C-DIODE KDS4148U ( 1) 223283R2
U001
D132 C-DIODE DA2J10100 1 223303R2 N
U001
D132 or C-DIODE KDS4148U ( 1) 223283R2
