1/52 PAGE
HT-R548
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
<B> : Black model
<S> : Silver model
<MPP> : 230V,CE(European) country model
<MMQ> : 220-240V,Hong kong model
EV
EXPLODED VIEW PARTS LIST
EV
EV
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EV
[CHASSIS SCREW]
EV
A001 CHASSIS TX-SR307 1 27100532E
EV
A003 LEG (B) 4 27175464
EV
A005 CUSHION (ZUL) 4 28141877
EV
A007 SCREW 3TTB+8B(3BC) 4 838430088GR
EV
A009 HOLDER KGLS-8RT 3 27190503A
EV
A010 HOLDER KGPS-8RF 1 27191044
EV
A011 HOLDER KGLS-10RT 1 27190428A
EV
A013 HOLDER KGPS-14RF 2 27190802
EV
A015 HOLDER KGPS-14RF 1 27190802
EV
A017 HOLDER KGLS-16S 1 27190607
EV
A019 HOLDER KGPS-16RF 1 27190991
EV
A021 HOLDER KGLS-22S 2 27190369
EV
A025 SCREW 4TTC+8C(3BC) 4 830440089GR
EV
A030 HEAT SINK 309P-1 1 27160657
N
EV
A032 RETAINER (HL) 1 27142159
EV
A034 RETAINER (HR) 1 27142223A
EV
A036 SCREW 3TTB+8B(3BC) 4 838430088GR
EV
A038 SCREW 3TTB+8B(3BC) 2 838430088GR
EV
A040 SCREW 3TTB+8B(3BC) 3 838430088GR
EV
A041 CLIP CS-1U 1 27255004
EV
A042 SCREW 3TTB+8B(3BC) 2 838430088GR
EV
A043 SCREW 3TTB+8B(3CM)SR 1 801637
EV
A050 SCREW 3SMS8WSW+18B3CM 4 801636
EV
A054 SCREW 3TTB+8B(3BC) 1 838430088GR
EV
A055 TAPE TAPE(CLOTH-8U) 1 29110082
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
