General Specifications
Amplifier (Audio) section
Rated Output Power (IEC)
2 ch k 135 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
Dynamic Power (*)
(*)IEC60268-Short-term maximum output power
180 W (3 ≠, Front)
160 W (4 ≠, Front)
100 W (8 ≠, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20,000 Hz, half power)
Input Sensitivity and Impedance (1 kHz,100 W/8 ≠)
200 mV/50 k≠ (LINE (Unbalance))
2.5 mV/50 k≠ (PHONO MM)
Rated RCA Output Level and Impedance
150 mV/470 ≠ (PRE OUT)
470 mV/680 ≠ (SUBWOOFER PRE OUT)
Phono Overload
70 mV (MM 1 kHz, 0.5%)
Frequency Response
10 Hz - 100 kHz/i1 dB, j3 dB (Direct/Pure Audio)
Tone Control Characteristics
n10 dB, 100 Hz (BASS)
n10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio
106 dB (IHF-A, LINE IN, SP OUT)
80 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance
4 ≠ - 16 ≠
Headphone Output Impedance
390 ≠
Headphone Rated Output
200 mW (32 ≠, 1 kHz, 10% THD)
Tuner Section
FM Tuning Frequency Range
87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel
40
Network Section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
IEEE 802.11 a/b/g/n standard
(Wi-Fi
®
standard)
2.4 GHz/5 GHz band
BLUETOOTH Section
Communication system
BLUETOOTH Specification version 4.1+LE
Frequency band
2.4 GHz band
Modulation method
FHSS (Frequency Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
A2DP 1.2
AVRCP 1.3
HOGP-Host (Client)
HOGP-HID Device (Server)
HID Service (HIDS)
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 48y/15 m (*)
(*)The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a
microwave oven, static electricity, cordless phone,
reception sensitivity, antenna’s performance, operating
system, software application, etc.
General
Power Supply
AC 220-230 V, 50/60 Hz
Power Consumption
220 W
0.1 W (Stand-by)
65 W (No-sound)
2.9 W (Hybrid Standby)
Dimensions (W k H k D)
435 mm k 149 mm k 329 mm
17-1/8z k 5-7/8z k 12-15/16z
Weight
8.5 kg /18.7 lbs
Audio Inputs
Digital
OPTICAL 1 (GAME), 2 (TV/TAPE)
Maximum Fs: 192 kHz
COAXIAL 1 (BD/DVD), 2 (CBL/SAT)
Maximum Fs: 192 kHz
Analog
PHONO, CD, TV/TAPE, GAME, PC, CBL/SAT, BD/DVD
Audio Outputs
Analog
SUBWOOFER PRE OUT
LINE OUT L/R
Speaker Outputs
SPEAKERS A: FRONT L/R
SPEAKERS B: FRONT L/R
Phones
PHONES (Front, Ø1/4z/6.3 mm)
Others
USB: 2 (Front: Ver.2.0, 5 V/0.5 A, Rear: Ver.2.0, 5 V/1 A)
Ethernet: 1
RI REMOTE CONTROL: 1
IR IN: 1
IR OUT: 1
