AMPLIFIER SECTION
Power Output (FTC) All channels 22 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz with no more than 0.6 % total
harmonic distortion.
Continuous power output (DIN)
All channels 22 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz
Maximun power output (EIAJ)
5 x 28 watts at 6 ohms
Dynamic power output 2 x 26 watts at 6 ohms
2 x 22 watts at 8 ohms
Total Harmonic Distortion 0.6 % at rated power
IM Distortion 0.6 % at rated power
Damping Factor 40 at 8 ohms
Input Sensitivity and Impedance
DIGITAL INPUT DVD, HD (OPTICAL) 0.5 Vp-p, 75 ohms
DIGITAL INPUT VIDEO 2 (COAXIAL) 0.5 Vp-p, 75 ohms
LINE (DVD/CD, VIDEO 1, 2, HD, TAPE/MD)
150 mV/50 kohms
Composite (DVD/CD, VIDEO 1, 2) 1 Vp-p, 75 ohms
S-VIDEO (DVD/CD, VIDEO 1, 2) Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
TUNER SECTION
Tuning Range FM: 87.50 to 108.00 MHz (50 kHz steps)
AM: (USA and Canadian models)
530 to 1710 kHz (10 kHz steps)
Usable Sensitivity FM: Mono 11.2 dBf, 1.0 µV (75 ohms IHF)
0.9 µV (75 ohms DIN)
Stereo 17.2 dBf, 2.0 µV (75 ohms IHF)
23 µV (75 ohms DIN)
AM: 30 µV
50 dB Quieting Sensitivity FM: Mono 17.2 dBf, 2.0 µV (75 ohms)
Stereo 37.2 dBf, 20.0 µV (75 ohms)
Capture Ratio FM: 2.0 dB
Image Rejection Ratio FM: (USA and Canadian models)
40 dB
AM: 40 dB
IF Rejection Ratio FM: 90 dB
AM: 40 dB
Signal-to-noise Ratio FM: Mono 76 dB, IHF
Stereo 70 dB, IHF
AM: 40 dB
Alternate Channel Att. (+/– 400 kHz) FM: Mono 55 dB, IHF
Selectivity FM: 50 dB, DIN
AM Suppression Ratio FM: 50 dB
Harmonic Distortion FM: Mono 0.2 %
Stereo 0.3 %
AM: 0.7 %
Frequency response FM: 30 to 15,000 Hz (+/– 1.0 dB)
Stereo Separation FM: 45 dB at 1,000 Hz
30 dB at 100 to 10,000 Hz
Stereo Threshold FM: 17.2 dBf, 20 µV (75 ohms)
GENERAL
Power Supply Rating (USA and Canadian models)
and Power Consumption AC 120 V, 60Hz 120W
(Some Asian models)
AC 220-230 V, 50/60Hz 105W
(Other models)
AC 230-240 V, 50Hz 105W
Specifications and features are subject to change without notice.
Output Level and Impedance
REC OUT (VIDEO 1, TAPE/MD, HD) 150 mV, 2.2 kohms
SUB WOOFER PRE OUT 1 V, 2.2 kohms
Composite (MON OUT, VIDEO 1) 1 Vp-p, 75 ohms
S-VIDEO (MON OUT, VIDEO 1) Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
Frequency Response 10 to 70,000 Hz : +/– 1.5 dB
Acoustic Control 1: +6 dB at 40 Hz
2: +10 dB at 40 Hz
+7 dB at 10,000 Hz
Signal-to-noise Ratio 100 dB (IHF)
Muting – dB
(Other models)
522 to 1611 kHz (9 kHz steps)
(Other models)
85 dB
Dimensions (W x H x D)
435 x 81 x 377 mm (17-
1
/
8
x
3-
3
/
16
x 14-
13
/
16
ins.)
Weight 6.1 kg (13.4 lb.)
8
TX-L5
SPECIFICATIONS
