Onkyo TX-NR1000

151
Specifications —Continued
Tuner Section
FM
AM
Specifications and features are subject to change without
notice.
Output Level and Impedance:
Audio
AUDIO 1-5: 200 mV, 470 Ω (Tape 1/2/ Video
1/2/3 Rec Out)
100 mV, 470
Ω (Zone 2/3 Out
(fixed))
1 V, 470
Ω (Zone 2/3 Out (variable))
PRE OUT A: 1 V, 470
Ω (Front L/R, CENTER,
SURR L/R, SURR BACK or
Zone 2 L/R, SUB WOOFER)
PRE OUT B: 1 V, 470
Ω (SUB WOOFER)
Video
VIDEO 1-4
(Composite Video): 1 Vp-p 75
Ω (Monitor Out A/B,
Video 1/2/3 Rec Out, Zone 2/3
Out)
VIDEO 1-4
(S Video, Y signal): 1 Vp-p, 75
Ω (Monitor Out A/B,
Video 1/2/3 Rec Out)
VIDEO 1-4
(S Video, C signal): 0.28 Vp-p, 75 ohms (Monitor Out
A/B, Video 1/2/3 Rec Out)
COMPONENT VIDEO: 1 Vp-p, 75 ohms (Y)
0.7 Vp-p, 75 ohms (P
B
/C
B
, P
R
/C
R
)
Phono Overload: 120 mV RMS at 1,000 Hz, 0.5%
THD
Frequency Response:
Audio (CD in Direct mode) 5 Hz-100 kHz: +1/–3 dB
Video Component 10 Hz-50 MHz: +1/–3 dB
RIAA Deviation: 20-20 kHz: ±0.8 dB
Tone Control: ±12 dB at 50 Hz (Bass)
±12 dB at 1,000 Hz (Mid)
±12 dB at 20,000 Hz (Treble)
S/N (Direct mode): 80 dB (PHONO, IHF A, 5 mV
input)
95 dB (LINE, IHF A, 0.5V input)
Muting: Due to setup menu
Tuning frequency Range:
USA & Canadian models: 87.50 to 108.00 MHz, 200 kHz
steps
Other models: 87.50 to 108.00 MHz, 50 kHz steps
Usable Sensitivity:
Stereo 17.2 dBf, 2.0 µV (75
Ω IHF)
23 µV (75
Ω DIN)
Mono 11.2 dBf, 1.0 µV (75
Ω IHF)
0.9 µV (75
Ω DIN)
50 dB Quieting Sensitivity:
Mono 17.2 dBf, 2.0 µV (75 ohms)
Stereo 37.2 dBf, 20.0 µV (75 ohms)
Capture Ratio: 2.0 dB
Image Rejection Ratio: 85 dB (UDD, UDC: 40dB)
IF Rejection Ratio: 90 dB
S/N:
Mono 76 dB, IHF
Stereo 70 dB, IHF
Alternate Channel Attenuation:
Mono 55 dB IHF
Selectivity: 50 dB DIN
AM Suppression Ratio: 50 dB
Harmonic Distortion:
Mono 0.2%
Stereo 0.3%
Frequency Response: 30 to 15,000 Hz, +/–1.0 dB
Stereo Separation: 45 dB at 1,000 Hz
30 dB at 100 to 10,000 Hz
Stereo Threshold: 17.2 dBf, 2.0 µV (75
Ω )
Tuning frequency Range:
USA & Canadian models: 530 to 1710 kHz, 10 kHz steps
European & Australian models:522 to 1611 kHz, 9 kHz steps
Asian models: 522 to 1611 kHz, 9 kHz steps or
530 to 1710 kHz, 10 kHz steps
*selectable
Usable Sensitivity: 30 µV
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 40 dB
S/N: 40 dB
THD: 0.7%
