150
Specifications
General
Amplifier Section
Power Supply Rating
North American and some
Asian models: AC 120 V, 60 Hz
European & Australian models:
AC 230-240 V, 50 Hz
Asian models: AC 220-230 volts, 50 Hz
Consumption Power
USA & Canadian models: 13.8 A
European & Australian models:
1,200 W
Asian models: 1,200 W
Standby Power Consumption: 3.9 W
Dimensions (W
×
H
×
D): 435
×
220
×
480.5 mm
(17 1/8"
×
8 11/16"
×
18 15/16)"
Weight: 33 kg (72.8 lbs)
Inputs:
Audio
Multichannel (7.1ch) Inputs:2
Phono (MM): 1
Line inputs: 9 (assignable), 1 (fixed) (Video 7
on the front panel)
Digital inputs Coaxial: 6
Digital inputs Optical: 6 (assignable), 1 (fixed) (Video 7
on the front panel)
Video
Composite Video inputs: 6 (assignable),
1 (fixed, on the front panel)
S Video inputs: 6 (assignable),
1 (fixed, on the front panel)
Component Video RCA
inputs: 4 (USA & Canadian models),
3 (others)
Component Video BNC
input: 1 (other than USA & Canadian
models)
Audio and Video
HDMI inputs (19-pin): 2
Miscellaneous
3-IR in (1/8-inch mini-jack) for
Main, Zone 2 and Zone 3
Outputs:
Audio
Speakers A: Front L/R, Center, Surround L/R,
Surround Back L/R
Speakers B: Front L/R, Center, Surround L/R,
Surround Back L/R or Powered
Zone 2 L/R
Pre out A: Front L/R, Center, Surround L/R,
Surround Back L/R, Subwoofer
Pre out B: Subwoofer
Headphones: 1
Line outputs: 5 (assignable to Recout, Zone 2 out
and Zone 3 out)
Digital outputs Coaxial: 2 (assignable to Recout, Zone 2 out
and Zone 3 out)
Digital outputs Optical: 2 (assignable to Recout, Zone 2 out
and Zone 3 out)
Video
Composite Video outputs: 3 (assignable to Monitor out A/B,
Recout, Zone 2 out and Zone 3 out)
1 (fixed, Monitor out A)
S Video outputs: 3 (assignable to Monitor out A/B
and Recout)
1 (fixed, Monitor out A)
Component Video RCA
outputs: 2 (USA & Canadian models),
1 (others)
Component Video BNC
output: 1 (other than USA & Canadian
models)
Audio and Video
HDMI output (19-pin): 1
Miscellaneous
IR out (1/8-inch mini-jack): 3 (for Main, Zone 2 and Zone 3)
12V Trigger out (1/8-inch
mini-jack): 5 (for A, B, C, D, E)
Inputs/Outputs:
Miscellaneous
i. LINK(AUDIO) (4 pin): 2
Ethernet (Net-Tune): 1
(1/8-inch mini-jack):
1
RS232 (9 pin D-SUB
Female connector): 1
Antennas:
FM: 75 ohms unbalanced
AM: Included loop antenna and external
terminal
AC Inlet: 1 (IEC type)
AC Outlets:
USA & Canadian models: 1 (Switched, 120 W 1A max.)
Asian & Australian models: 1 (Switched, 100 W max.)
Power Output (All channels):
USA & Canada (FTC):
150 Watts per channel min. RMS
into 8 ohms 2 channel driven,
from 20 to 20,000 Hz with no
more than 0.05% total harmonic
distortion.
200 Watts per channel min. RMS
into 6 ohms 2 channel driven, 1,000
Hz with no more than 0.1% total
harmonic distortion.
260 Watts per channel min. RMS
into 8 ohms 2 channel driven,
1,000 Hz with no more than 0.1%
total harmonic distortion. [BTL]
Europe (DIN):
200 Watts per channel min. RMS
into 6 ohms 2 channel driven, 1,000
Hz DIN
280 Watts per channel min. RMS
into 8 ohms 2 channel driven, 1,000
Hz DIN [BTL]
Asia (JEITA): 2
×
240 Watts into 6 ohms, 1,000
Hz (EIAJ)
2
×
350 Watts into 8 ohms, 1,000
Hz (EIAJ) [BTL]
Dynamic Power:
2
×
340 W (3
Ω
,
2 channel driven)
2
×
260 W (4
Ω
, 2 channel driven)
2
×
175 W (8
Ω
, 2 channel driven)
THD (Total Harmonic Distor-
tion): 0.05% (rated power)
0.05% (1 watt output)
Damping Factor: 60 at 8 ohms
IM Distortion: 0.05% (rated power)
0.05% (1 watt output)
Input Sensitivity and Impedance:
Audio 200 mV, 50 k
Ω
(AUDIO IN 1-9/
FRONT)
2.5 mV, 50 k
Ω
(PHONO MM)
200 mV, 50 k
Ω
(MULTI IN FR/FL/
C/SR/SL/SBR/SBL)
36 mV, 50 k
Ω
(MULTI IN SUB)
0.5 Vp-p, 75
Ω
(DIGITAL IN
COAXIAL 1-6)
Video (DVD, VIDEO 1-5) 1 Vp-p, 75
Ω
(Composite Video)
1 Vp-p, 75
Ω
(S Video, Y signal)
0.28 Vp-p, 75
Ω
(S Video, C signal)
Component 1 Vp-p, 75
Ω
(Y)
0.7 Vp-p, 75
Ω
(P
B
/C
B
, P
R
/C
R
)
