Onkyo TX-NR3007

1/219 PAGE
TX-NR3007
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model
(S) : Silver model
<MDC> : Canadian model
<MMP> : European model
<MMO> : Asian model
EXPLODED VIEW PARTS LIST
REF. NO
.
PART NAME DESCRIPTION Q'TY PART NO. (SN)
REMARKS
EXPLODE
D
[SEMI CONDUCTOR]
EXPLODE
D
Q6050 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6050A ISO SHEET ISO SHEET(NR5007_4CH) 1 223052
EXPLODE
D
Q6051 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6051A ISO SHEET ISO SHEET(NR5007_5CH) 1 223051
EXPLODE
D
Q6052 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6053 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6054 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6055 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6056 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6057 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6058 TR TTC0002(Q)TO3PL 1 2204150
EXPLODE
D
Q6060 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q6060A ISO SHEET ISO SHEET(NR5007_4CH) 1 223052
EXPLODE
D
Q6061 TR TTA0002(Q)TO3PL 1 2204140
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
