Onkyo TX-NR3007

2/219 PAGE
EXPLODE
D
Q6061A ISO SHEET ISO SHEET(NR5007_5CH) 1 223051
EXPLODE
D
Q6062 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q6063 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q6064 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q6065 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q6066 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q6067 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q6068 TR TTA0002(Q)TO3PL 1 2204140
EXPLODE
D
Q9427 TR 2SB1565-E 1 2202715
EXPLODE
D
Q9427or TR 2SA1488-Y ( 1) 2203394
EXPLODE
D
Q9428 TR 2SD2394-E 1 2202705
EXPLODE
D
Q9428or TR 2SC3851-Y ( 1) 2203384
EXPLODE
D
Q9429 TR 2SB1565-E 1 2202715
EXPLODE
D
Q9429or TR 2SA1488-Y ( 1) 2203394
EXPLODE
D
Q9430 TR 2SD2394-E 1 2202705
EXPLODE
D
Q9430or TR 2SC3851-Y ( 1) 2203384
EXPLODE
D
[TRANS COIL]
EXPLODE
D
T901 P TRANS NPT-1553D 1 2301893
!, <MDC>
EXPLODE
D
T901 P TRANS NPT-1553M 1 2301894
!, <MMO, MMP>
EXPLODE
D
T903 P TRANS NPT-1581D 1 2301952
!, <MDC>
EXPLODE
D
T903 P TRANS NPT-1581M 1 2301953
!, <MMO, MMP>
EXPLODE
D
T904 P TRANS NPT-1582D 1 2301955
!, <MDC>
EXPLODE
D
T904 P TRANS NPT-1582M 1 2301956
!, <MMO, MMP>
EXPLODE
D
[SW TRM]
EXPLODE
D
F2001 FUSE 4A-UL/T-233 1 252325GR !
EXPLODE
D
F2001 or FUSE 4A-T/UL-ST2 ( 1) 252257GR !
EXPLODE
D
F2004 FUSE 1.25A-UL/T-233 1 252318GR !
EXPLODE
D
F2004 or FUSE 1.25A-T/UL-ST2 ( 1) 252251GR !
EXPLODE
D
F2005 FUSE 1.25A-UL/T-233 1 252318GR !
EXPLODE
D
F2005 or FUSE 1.25A-T/UL-ST2 ( 1) 252251GR !
EXPLODE
D
F6601 FUSE 20A-UL-250V 1 252304GR !
EXPLODE
D
F6602 FUSE 20A-UL-250V 1 252304GR !
EXPLODE
D
F6603 FUSE 20A-UL-250V 1 252304GR !
