Onkyo TX-NR3007

3/219 PAGE
EXPLODE
D
F6604 FUSE 20A-UL-250V 1 252304GR !
EXPLODE
D
F9100 FUSE 12A-UL-ST6 1 252340GR
!, <MDC>
EXPLODE
D
F9100 FUSE 6.3A-SE-EAK FUSE 1 252079GR
!, <MMO, MMP>
EXPLODE
D
F9100 or FUSE 6.3A-SE-TL250V ( 1) 252279GR
!, <MMO, MMP>
EXPLODE
D
F9301 FUSE 3.15A-UL/T-233 1 252323GR !
EXPLODE
D
F9301 or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR !
EXPLODE
D
F9401 FUSE 3.15A-UL/T-233 1 252323GR !
EXPLODE
D
F9401 or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR !
EXPLODE
D
F9402 FUSE 3.15A-UL/T-233 1 252323GR !
EXPLODE
D
F9402 or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR !
EXPLODE
D
JL4103 JMP LEAD JL5 550H 1
--- NSP
EXPLODE
D
P061 FAN D09A-12PG13 1 24502328
EXPLODE
D
P062 FAN D09A-12PG13 1 24502328
EXPLODE
D
P106 FFC NCFC7-111012 1 2047111012
EXPLODE
D
P3101 SOCKET AS NSAS-10P1813 1 2009991173UL
EXPLODE
D
P4008 FFC NCFC7-090512 1 2047090512
EXPLODE
D
P4009 FFC NCFC7-150512 1 2047150512
EXPLODE
D
P4104 FFC NCFC7-311012 1 2047311012
EXPLODE
D
P7501 SOCKET AS NSAS-80P1788 1 2009991154UL
EXPLODE
D
P8641 FFC NCFCD-31007 1 204D31007
EXPLODE
D
P9008 SOCKET AS NSAS-6P1675 1 2009991073UL <MMO, MMP>
EXPLODE
D
[CHASSIS SCREW]
EXPLODE
D
A001 HEAT SINK (5) 1 27160634
EXPLODE
D
A003 HEAT SINK (4) 1 27160635
EXPLODE
D
A005 SPACER (PC) 8 27270485
EXPLODE
D
A007 SCREW 3P+6FN(3BC) 8 82143006GR
EXPLODE
D
A009 SCREW 3SMS8W.SW+14B(CU) 18 801634
EXPLODE
D
A011 RETAINER (HS-2) 2 27141530A
EXPLODE
D
A013 SCREW 3TTB+8B(3CM)SR 4 801637
EXPLODE
D
A017 RETAINER (HS-C) 1 27142151
EXPLODE
D
A019 SCREW 3TTB+8B(3CM)SR 8 801637
EXPLODE
D
A021 RETAINER (HS-L) 1 27142152
EXPLODE
D
A023 SCREW 3TTB+8B(3CM)SR 4 801637
