Onkyo TX-NR3007

8/219 PAGE
EXPLODE
D
A403 BADGE BADGE 1 28135244 (B)
EXPLODE
D
A403 BADGE --- 1 28135298 (S)
EXPLODE
D
A404 CLEAR PLT (AS) NR3007 1 28192269 N
EXPLODE
D
A405 KNOB (VOL)AS 1007B 1 28326696A (B)
EXPLODE
D
A405 KNOB (VOL)AS 1007S 1 28326697A (S)
EXPLODE
D
A406 CUSHION --- 1 28141528GR
EXPLODE
D
A407 DOOR SR3007(B)MDC 1 28148740 N (B) <MDC>
EXPLODE
D
A407 DOOR SR3007(B)MMP/MO 1 28148741 N (B) <MMO, MMP>
EXPLODE
D
A407 DOOR SR3007(S)MMP 1 28148742 N (S)
EXPLODE
D
A411 KNOB (POW) (B) 1 28326454 (B) <MMO, MMP>
EXPLODE
D
A411 KNOB (POW)(S) 09 1 28326729 (S)
EXPLODE
D
A413 SCREW 3P+6FN(3BC) 2 82143006GR <MMO, MMP>
EXPLODE
D
A415 SCREW 3TTB+8B(3CM)SR 2 801637 <MMO, MMP>
EXPLODE
D
A551 COVER (B) (Bent) 1 28210040A (B)
EXPLODE
D
A551 COVER (B) (Not Bent) 1 28210040AZ (B)
EXPLODE
D
A551 COVER (S) (Bent) 1 28210041A (S)
EXPLODE
D
A553 LABEL (CAUTION) 1 29363797 (S)
EXPLODE
D
A553 LABEL (COVER) 1 29364123 (B)
EXPLODE
D
A555 ST SCREW 4TTB+8C(NI) 6 838240089 (S)
EXPLODE
D
A555 SCREW 4TTB+8C(3BC) 6 838440089GR (B)
EXPLODE
D
A557 SCREW 3TTB+8B(3BC) 3 838430088GR (B)
EXPLODE
D
A561 LABEL HOOKUP-ONKYO 1 29363194 <MDC>
EXPLODE
D
A694 CUSHION (FNP) t25x15x10 1 28141828
EXPLODE
D
[TUNER UNIT]
EXPLODE
D
U001 U0010 + U0011 + U0012 + U0013 + U0014 BAAF-0180-1A * 1 1B234580-1A
N
EXPLODE
D
U0010 POWER SUPPLY PC board ass'y BAAF-0180-1A 1 1B2345180-1A N
EXPLODE
D
U0011 DIODE PC board ass'y BAPS-0181-1A 1 1B2345181-1A N
EXPLODE
D
U0012 RELAY PC board ass'y BAPS-0182-1A 1 1B2345182-1A N
EXPLODE
D
U0013 THERMAL SENSOR PC board ass'y BAETC-0183-1A 1 --- N NSP
EXPLODE
D
U0014 THERMAL SENSOR PC board ass'y BAETC-0184-1A 1 --- N NSP
EXPLODE
D
U002 U0020 + U0021 BAAMP-0191-1A * 1 1B234591-1A
N
EXPLODE
D
U0020 AMPLIFIER PC board ass'y (C,SR,RH,SBR,R) BAAMP-0191-1A 1 1B2345191-1A N
EXPLODE
D
U0021 AMPLIFIER PC board ass'y (L,SBL,LH,SL) BAAMP-0192-1A 1 1B2345192-1A N
