Onkyo TX-NR3007 - Page 70

9/219 PAGE
EXPLODE
D
U003 U0030 + U0031 BAASP-0202-1D * 1 1B234502-1D
N
EXPLODE
D
U0030 ANALOG AUDIO PC board ass'y BAASP-0202-1D 1 1B2345202-1D N
EXPLODE
D
U0031 ANALOG VIDEO PC board ass'y BAVD-0203-1D 1 1B2345203-1D N
EXPLODE
D
U004 U0040 + U0041 + U0041 + U0043 + U0044 BADG-0208-1A * 1 1B234508-1A
N <MDC>
EXPLODE
D
U004 + U0045 + U0046 BADG-0208-1B * 1 1B234508-1B
N <MMP>
EXPLODE
D
U004 BADG-0208-1B * 1 1B234508-1B
N <MMO>
EXPLODE
D
U0040 DAC PC board ass'y BADG-0208-1A 1 1B2345208-1A N <MDC>
EXPLODE
D
U0040 DAC PC board ass'y BADG-0208-1B 1 1B2345208-1B N <MMP>
EXPLODE
D
U0040 DAC PC board ass'y BADG-0208-1B 1 1B2345208-1B N <MMO>
EXPLODE
D
U0041 MAIN CPU PC board ass'y BACPU-0209-1A 1 1B2345209-1A N <MDC>
EXPLODE
D
U0041 MAIN CPU PC board ass'y BACPU-0209-1B 1 1B2345209-1B N <MMP>
EXPLODE
D
U0041 MAIN CPU PC board ass'y BACPU-0209-1B 1 1B2345209-1B N <MMO>
EXPLODE
D
U0042 ZONE-2 & ZONE-3 PC board ass'y BAAR-0210-1A 1 1B2345210-1A N <MDC>
EXPLODE
D
U0042 ZONE-2 & ZONE-3 PC board ass'y BAAR-0210-1B 1 1B2345210-1B N <MMP>
EXPLODE
D
U0042 ZONE-2 & ZONE-3 PC board ass'y BAAR-0210-1B 1 1B2345210-1B N <MMO>
EXPLODE
D
U0043 PHONO AMP. PC board ass'y BAAF-0211-1A 1 1B2345211-1A N <MDC>
EXPLODE
D
U0043 PHONO AMP. PC board ass'y BAAF-0211-1B 1 1B2345211-1B N <MMP>
EXPLODE
D
U0043 PHONO AMP. PC board ass'y BAAF-0211-1B 1 1B2345211-1B N <MMO>
EXPLODE
D
U0044 BUFFER AMP. PC board ass'y BAACC-0212-1A 1
1B2345212-1A
N
<MDC>
EXPLODE
D
U0044 BUFFER AMP. PC board ass'y BAACC-0212-1B 1
1B2345212-1B
N
<MMP>
EXPLODE
D
U0044 BUFFER AMP. PC board ass'y BAACC-0212-1B 1
1B2345212-1B
N
<MMO>
EXPLODE
D
U0045 SIRIUS PC board ass'y BARF-0204-1A 1
1B2345204-1A
N
<MDC>
EXPLODE
D
U0045 SIRIUS PC board ass'y BARF-0204-1B 1 1B2345204-1B N <MMP>
EXPLODE
D
U0045 SIRIUS PC board ass'y BARF-0204-1B 1 1B2345204-1B N <MMO>
EXPLODE
D
U0046 DG AUDIO IN PC board ass'y BAETC-0246-1A 1 --- N NSP, <MDC>
EXPLODE
D
U0046 DG AUDIO IN PC board ass'y BAETC-0246-1B 1 --- N NSP, <MMP>
EXPLODE
D
U0046 DG AUDIO IN PC board ass'y BAETC-0246-1B 1 --- N NSP, <MMO>
EXPLODE
D
U005 U0050 + U0051 + U0052 + U0053 + U0054 BADIS-0135-1B * 1 1B234535-1B
N <MDC>
EXPLODE
D
U005 + U0055 + U0056 + U0057 + U0058 BADIS-0135-1D * 1 1B234535-1D
N <MMP>
EXPLODE
D
U005 + U0059 + U00510 BADIS-0135-1D * 1 1B234535-1D
N <MMO>
EXPLODE
D
U0050 DISPLAY PC board ass'y BADIS-0135-1B 1 1B2345135-1B N <MDC>
EXPLODE
D
U0050 DISPLAY PC board ass'y BADIS-0135-1D 1 1B2345135-1D N <MMP>
EXPLODE
D
U0050 DISPLAY PC board ass'y BADIS-0135-1D 1 1B2345135-1D N <MMO>
