Onkyo TX-NR535 Series

1/37 PAGE
TX-NR535(B)MDC
<Note>
Parts marked by "NSP" are generally unavailable because
<Notes>
they are not in our Master Spare Parts List.
(B) : Black color model
<MDC> : 120V
Canadian/USA/(Mexico) model
: NSP
TX-NR535(B)MDC
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TRANSISTOR 2SC5198-O 1 2203063
Q6050 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6050 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6050 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6051 TRANSISTOR 2SC5198-O 1 2203063
Q6051 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6051 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6051 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6052 TRANSISTOR 2SC5198-O 1 2203063
Q6052 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6052 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6052 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6053 TRANSISTOR 2SC5198-O 1 2203063
Q6053 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6054 TRANSISTOR 2SC5198-O 1 2203063
Q6054 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6060 TRANSISTOR 2SA1941-O 1 2203053
Q6060 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6060 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6060 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6061 TRANSISTOR 2SA1941-O 1 2203053
Q6061 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6061 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6061 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6062 TRANSISTOR 2SA1941-O 1 2203053
Q6062 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6062 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6062 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6063 TRANSISTOR 2SA1941-O 1 2203053
Q6063 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6064 TRANSISTOR 2SA1941-O 1 2203053
Q6064 or TRANSISTOR 2SA1941-R ( 1) 2203052
[CHASSIS SCREW]
A003 LEG (B) 4 27175464
A005 CUSHION (ZUL) 4 28141877
A081A LABEL (E-CON) { 1} 29364978
A101 REAR PANEL 535MDC 1 27124548C
N
A129 LABEL (SP)525 1 29392277
[CABINET]
A201 FRONT PANEL TXNR535(B)DC 1 27213707A
N
A203 CLEAR PLATE 535(B)D 1 28192423
N
A205 BADGE 1 28135317
A207 KNOB (TONE)(B) 1 28326912
A209 KNOB (INP)B_535 1 28327172A
N
A211 KNOB (SEL) 1 28326906B
A213 KNOB (INP-L)B_535 1 28327174C
N
A214 KNOB (INP-R)B_535 1 28327175C
N
A215 FACET (KNOB)_535 2 28200076
N
A217 KNOB (STBY)(B) 1 28326904
A219 KNOB (CUR) 1 28326907B
A221 KNOB (VOL)AS(B)_525 1 28327142
A229 SHEET (WIFI) 1 29096161
A401 COVER (B) (Bent) 1 28210089A
A401 COVER (B) (Not Bent) 1 28210089AZ
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
