Onkyo TX-NR535 Series

2/37 PAGE
A411 LABEL (CAUTION) 1 29392531
[TRANS COIL]
T901 POWER TRANSFORMER NPT-1639D 1 2302088
N, !
[SW TRM]
F6401 FUSE 10A-UL/T-233 1 252330GR
!
F6401 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
F6402 FUSE 10A-UL/T-233 1 252330GR
!
F6402 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
F9002 FUSE 8A-UL/T-233 1 252329GR
!
P701 FLEXIBLE FLAT CABLE NCFC5-232512 1 2045232512
P9001 POWER SUPPLY CORD AS-UC-2 1 253368AYUN
!
P9001 or POWER SUPPLY CORD AS-UC-2 ( 1) 253368BLTK
!
[TUNER UNIT]
U001 U0010, U0011, U0012 BAAF-1511-1A * (Parent) 1 1B299511-1A MDC
U0010 AMP/ ASP PC BOARD AS BAAF-1511-1A (Child) 1 1B2995511-1A
U0011 SENSOR(THERMAL) PC BOARD AS BAETC-1512-1A (Child) 1 1B2995512-1A
U0012 FIX(THERMAL) PC BOARD AS BAETC-1513-1A (Child) 1 1B2995513-1A
U003 U0030, U0031, U0032 x 2 pcs. BACLA-1522-1A * (Parent) 1 1B299522-1A MDC
U0030 AMP(CLASS-A) PC BOARD AS BACLA-1522-1A (Child) 1 1B2995522-1A
U0031 FIX(FFC) PC BOARD AS BAETC-1523-1A (Child) 1 1B2995523-1A
U0032 FIX(HP CABLE) PC BOARD AS BAETC-1528-1A (Child) 1 1B2995528-1A
U004 U0040, U0041, U0042, U0043, U0044 BADIS-1524-1A * (Parent) 1 1B299524-1A MDC
U0040 DISPLAY PC BOARD AS BADIS-1524-1A (Child) 1 1B2995524-1A
U0041 KEY/ LED PC BOARD AS BASW-1525-1A (Child) 1 1B2995525-1A
U0042 TERMINAL (SPEAKER/ VIDEO) PC BOARD AS BATRM-1526-1A (Child) 1 1B2995526-1A
U0043 PHONE JACK PC BOARD AS BAETC-1527-1A (Child) 1 1B2995527-1A
U0044 CONNECTOR PC BOARD AS BAETC-1529-1A (Child) 1 1B2995529-1A
U007 U0070, U0071 x 2 pcs. BADG-1559-1A * (Parent) 1 1B299559-1A MDC
U0070 DAC/ FILTER PC BOARD AS BADG-1559-1A (Child) 1 1B2995559-1A
U0071 POWER SIPPLY(PRI) PC BOARD AS BAPS-1560-1A (Child) 1 1B2995560-1A
U008 U0080 x 2 pcs. BAPRC-1563-1A * (Parent) 1 1B299563-1A MDC
U0080 PROCESSING (DSP/MPU/DAC) PC BOARD AS BAPRC-1563-1A (Child) 1 1B2995563-1A
U009 U0090 x 25 pcs. BARF-1567-1A * (Parent) 1 1B299567-1A MDC
U0090 CONNCTOR(Wifi)/ BPF PC BOARD AS BARF-1567-1A (Child) 1 1B2995567-1A
U012 U0120 x 25 pcs. BARF-1450-2A * (Parent) 1 1B300550-2A MDC
U0120 TUNER PC BOARD AS BARF-1450-2A (Child) 1 1B3005450-2A
U0120A SHLD CASE (TUNER-TOP) 1 27225206A
U0120B SHLD CASE (TUNER-BTM) 1 27225207A
U791 WIFI MODULE (U791A+U791B+U791C) WCBN4601L-O1(wANT_IN) 1 24850701
U791A ASSEMBLED PWB WCBN4601L-O1 { 1} 24150122
U791B WIFI BT ANTENA 2.4GHZ ANT L1 { 1} 2050091
U791C WIFI BT ANTENA 2.4GHZ ANT R1 { 1} 2050092
