Appendix
Speaker Combinations
• Up to two powered subwoofers can be connected in either combination.
(North American models)
Speaker
Channels
FRONT CENTER SURROUND
SURROUND
BACK
HEIGHT 1 HEIGHT 2 Bi-AMP (*3)
ZONE 2 (*3)
(ZONE SPEAKER)
ZONE 3 (*3)
(ZONE SPEAKER)
2.1 c h
3.1 c h
4.1 ch
5.1 c h
6.1 ch (*1)
7.1 ch (*1)
2.1.2 ch (*2)
(*4) (*5) (*5) (*4) (*4)
3.1.2 ch (*2)
(*4) (*5) (*5) (*4) (*4)
4.1.2 ch (*2)
(*4) (*5) (*5) (*4) (*4)
5.1.2 ch (*2)
(*4) (*5) (*5) (*4) (*4)
6.1.2 ch (*1)
(*6) (*6)
7.1.2 ch (*1)
(*6) (*6)
4.1.4 ch (*1)
(*6) (*6)
5.1.4 ch (*1)
(*6) (*6)
6.1.4 ch (*1)
(*7) (*6) (*6)
7.1.4 ch (*1)
(*7) (*6) (*6)
(*1) The "Connecting an Integrated Amplier (ZONE 3)" ( →p72) function cannot be used.
(*2) When using Bi-AMP or ZONE 2 (ZONE SPEAKER), the "Connecting an Integrated Amplier (ZONE 3)" ( →p72) function cannot be used. However, if a power
amplier is connected to the ZONE 3 PRE/LINE OUT jacks in the "Connecting an Integrated Amplier (ZONE 3)" ( →p72) function, ZONE 2 (ZONE SPEAKER)
and ZONE 3 (ZONE SPEAKER) can be used.
(*3) The Bi-AMP and ZONE speakers cannot be used simultaneously.
(*4) When using the ZONE 2 speakers (except when the ZONE 3 is used), it is necessary to connect the height speakers to the SURROUND BACK terminal. When
using both the ZONE 2 speakers and the ZONE 3 speakers, the Height 1 speakers cannot be used simultaneously with the ZONE speakers.
(*5) When using the Bi-AMP speakers, it is necessary to connect the Bi-AMP speakers to the HEIGHT 1 terminals, and the height speaker to the SURROUND BACK
terminals.
(*6) Height 1 speakers cannot be used simultaneously with the ZONE speakers.
(*7) Use an analog audio cable to connect the power amplier to the PRE OUT SURROUND BACK jacks, then connect the surround back speakers to the power
amplier.
