Onkyo TX-RZ50

7.1.2ch
7.1ch
5.1. 2ch
5.1.4ch
7.1.4ch
5.1c h
25
Speaker Layout
5.1.2 Channel System
A Speaker System that is a 5.1 Channel System with one set of height speakers added.
5.1.2 ch (Front High or Rear High) ( →p34) 5.1.2 ch (Top Front or Top Middle or Top Rear)
( →p34)
5.1.2 ch (Dolby Enabled Speakers (Front or
Surround)) ( →p34)
Zone 2Zone 2
Main Room
5.1.2 ch + ZONE 2 ( →p34) 5.1.2 ch (Bi-Amping (Front)) ( →p34)5.1.2 ch + ZONE 2/ZONE 3 (North American
models) ( →p34)
Zone 3Zone 3Zone 2Zone 2
Main Room
