Onkyo TX-RZ50

202
Appendix
General Specications
Amplier Section North American models European models Australian and Asian models
Rated Output Power
With 8 ohm loads, both channels
driven, from 20 Hz-20 kHz; rated
120 watts per channel minimum
RMS power, with no more than
0.08% total harmonic distortion from
250 milliwatts to rated output. (FTC)
9 ch × 180 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD (IEC)
Maximum Effective Output Power
250 W at 6 ohms, 1 kHz, 1 ch driven
of 10% THD
215 W at 6 ohms, 1 kHz, 1 ch driven
of 10% THD (JEITA)
9 ch × 215 W at 6 ohms, 1 kHz, 1 ch
driven of 10% THD (JEITA)
THD+N (Total Harmonic Distortion + Noise) 0.08% (20 Hz - 20,000 Hz, Rated output power)
Input Sensitivity and Impedance 200 mV/47 kΩ (LINE(RCA)), 3.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
PRE OUT : 1 V/470 Ω
PRE OUT(ZONE 2) : 1 V/2.2 kΩ
LINE OUT (ZONE 2, ZONE B): 200 mV/2.2 kΩ
LINE OUT (ZONE 3) : 200 mV/470 Ω
Phono Maximum Input Signal Voltage 70 mV (MM 1 kHz 0.5%)
Frequency Response 5 Hz - 100 kHz/+1 dB, –3 dB (Direct/Pure Audio)
Tone Control Characteristics
MAIN : ±10 dB, 20 Hz (BASS), ±10 dB, 20 kHz (TREBLE)
ZONE 2 : ±10 dB, 100 Hz (BASS), ±10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio 106 dB (IHF-A, LINE IN, SP OUT), 80 dB (IHF-A, PHONO IN, SP OUT)
Supported impedance of Speakers 4 Ω - 16 Ω
Headphone Rated Output 85 mW + 85 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones 8 Ω - 600 Ω
Headphones Frequency Response 5 Hz - 100 kHz
