Front Panel≫ Rear Panel≫ Remote≫
1. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI
cable connected to a TV.
2. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable
connected to an AV component.
3. POWER OUT port: The power (5 V/1 A) can be supplied to a streaming
media player, etc. using a USB cable. ( p29) The playback function is not
supported.
4. Power cord
5. DIGITAL IN OPTICAL/COAXIAL jacks: Input TV or AV component digital audio
signals with a digital optical cable or digital coaxial cable.
6. TUNER AM/FM terminal: Connect the supplied antennas.
7. AUDIO IN jacks: Input TV or AV component audio signals with an analog audio
cable.
8. ZONE B LINE OUT jacks: Output audio signals with an analog audio cable
connected to a pre-main amplier in a separate room (ZONE B).
9. SUBWOOFER PRE OUT jacks: Connect a powered subwoofer with a
subwoofer cable. Up to two powered subwoofers can be connected. The same
signal is output from each SUBWOOFER PRE OUT jack.
10. SPEAKERS terminals: Connect speakers with speaker cables. (FRONT L/R
terminals of North American models support banana plugs.)
