❏ Dolby Enabled Speakers (Dolby Speakers)
Installation Example
a
3
12
45
6
a: 22° to 30°
This is a 3.1-channel system consisting of front speakers, a center speaker, and
a powered subwoofer, with the addition of Dolby enabled speakers (front), a type
of height speaker. Dolby enabled speakers are special speakers designed to face
the ceiling, so that the sound is heard from overhead by bouncing the sound o
the ceiling. Installing the height speakers will enrich the sound eld feeling in the
upper space.
Place Dolby enabled speakers (front) above the front speakers.
1,2 Front Speakers
3 Center Speaker
4,5 Dolby Enabled Speakers (Front)
6 Powered Subwoofer
❏ Speaker Layouts and Selectable Listening
Modes ( p48)
