Onkyo TX-SR501/E - Printed Circuit Board-Parts List

PRINTED CIRCUIT BOARD-PARTS LIS
T
Dis
p
la
y
circuit PC board
(
NADIS-7403-2A/2B
)
CIRCUIT NO. PART NO.
DESCRIPTION
FL tube
Q7501 212229 HNA-16MM39T
Sensor
U7501 241341 SPS-444-1-E1,Remote control
IC
Q7502 22241571R3 MPD780232GC-030-8BT
Transistors
Q7503 2216175R2 or KTC3875-GR or
2213145R2 2SC2712-GR
Q7504 2216230R2 or KRA103S or
2214540R2 RN2403
Q7506 2216190R2 or KRC102S or
2214470R2 RN1402
Diodes
D7501 224550820R2, UDZS8.2B,
224490820R2 or UDZ8.2B or
224660824R2 HZU8.2B,Zener
D7502 224550510R2, UDZS5.1B,
224490510R2 or UDZ5.1B or
224660514R2 HZU5.1B,Zener
D7503,D7507 223269R2 or 1SS355 or
223234R2 1SS352
D7505 225290 SEL4110R,LED
Choke coils
L7504,L7505 231237K220R2 NCH-1477
Oscillato
r
X7501 3010242 CST5.00MGW,Ceramic
Ca
p
acitors
C7502 355783309 CE04W50V-33M,Elect.
C7514 394621017 or CE04W6.3V-100M
(
VR
)
or
394721017 CE04W6.3V100M
(
SC
)
,Elect.
C7521 355722219 CE04W6.3V-220M,Elect.
Rotar
y
encode
r
S7501 25065627 EC12E2425
Push switches
S7611~S7613 25035718, NPS-111-S681,
S7621~S7627 25035699 or NPS-111-S662 or
S7631~S7637 25035714 NPS-111-S677
S7641~S7647 25035718, NPS-111-S681,
25035699 or NPS-111-S662 or
25035714 NPS-111-S677
Sockets
JL7501A 25051107 NSCT-3P894
JL7502A 25051109 NSCT-5P896
P7502A 25051892 or NSCT-10P1679 or
25052477 NSCT-10P2374
P7503A 25052054 or NSCT-8P1841 or
25051852 NSCT-8P1639
Holder
Q7501A 27190989A
(
FL
)
Standb
y
switch PC board
(
NASW-7404-2A/2B
)
CIRCUIT NO. PART NO.
DESCRIPTION
Push switches
S7614~S7616 25035718, NPS-111-S681,
25035699 or NPS-111-S662 or
25035714 NPS-111-S677
Socket
JL7501B 25051107 NSCT-3P894
Head
p
hone terminal PC board
(
NAETC-7405-2A/2B
)
CIRCUIT NO. PART NO.
DESCRIPTION
P7501 25045724 YKB21-5005,Head
p
hone
JL7502B 25051109 NSCT-5P896,Socket
Front video PC board
(
NAETC-7406-2A/2B
)
CIRCUIT NO. PART NO.
DESCRIPTION
P251 25045680 NPJ-7PDB477,Terminal
P253B 2009990578UL NSAS-10P0787,Socket
P261B 2009990513UL NSAS-6P0675,Socket
Page 49
