EXPLODED VIEW-PARTS LIST
REF.NO. PART NO. DESCRIPTION
1 27111268 Front bracket <B>
27111269 Front bracket <S>
27111270 Front bracket <G>
2 838130088 3TTB+8B,Self-ta
pp
in
g
screw
3 82143010 3P+10FN
(
BC
)
,Pan head screw
4 28325497A Knob,
p
ower <B>
28325499A Knob,
p
ower <G>
28325547A Knob,
p
ower <S>
5 27100416A Chassis
6 27190503A KGLS-8RT,Holder
7 27190813 KGPS-10RF,Holder
8 27190428A KGLS-10RT,Holder
9 830440089 4TTC+8C
(
BC
)
,Self-ta
pp
in
g
screw
10 880009 NRP-345,Plastic rivet
11 27300750 ! Cord, bushin
g
12 27160527 Heatsink
13 801606 3SMH10W.SW+15B
(
CU
)
,S
p
ecial screw
16 28184831 To
p
cover <B>
28184856 To
p
cover <S>
28184857 To
p
cover <G>
17 838430088 3TTB+8B
(
BC
)
,Self-ta
pp
in
g
screw <B>
838930088 3TTB+8B
(
UN
)
,Self-ta
pp
in
g
screw <S/G>
18 29363194 Label,hooku
p
<D>
21 27175319B Le
g
22 28141494 Cushion
23 838130088 3TTB+8B,Self-ta
pp
in
g
screw
24 28325641 Knob volume <B>
28325642 Knob volume <S>
28325643 Knob volume <G>
25 28191957 Clear
p
late <B>
28191958 Clear
p
late <G/S>
31 27123068A Rear
p
anel <D>
27123069A Rear
p
anel <P>
27123070A Rear
p
anel <K>
27123071A Rear
p
anel <T/Q>
27123072A Rear
p
anel <R>
27123073A Rear
p
anel <A>
32 27191143 Holder, outlet <R>
33 838430088 3TTB+8B
(
BC
)
,Self-ta
pp
in
g
screw
51 27212471 Front
p
anel <D>
27212472 Front
p
anel <S><A/R>
27212473 Front
p
anel <B><P>
27212474 Front
p
anel <S><P>
27212475 Front
p
anel <B><A/T>
27212476 Front
p
anel <G>
27212534 Front
p
anel <S><C>
52 28135244 Bad
g
e <B>
28135245 Bad
g
e <S/G>
53 838430088 3TTB+8B
(
BC
)
,Self-ta
pp
in
g
screw
54 29110083 Ta
p
e, cloth
55 223024
A
C238,Isolated sheet
56 260208 Wire tie
63 29363379-1 Label PT
F6901,F6902 252198 or ! 8A-UL or
252261 ! 8A-T/UL-ST2 <D>
252099 ! 8A-EAK ,Fuse <O>
F901 252166 or ! 6.3A-UL/T-237 or
252260 ! 6.3A-T/UL-ST2,Fuse <D/T/Q/R>
F902 252076, ! 3.15A-SE-EAK,
252242 or ! 3.15A-SE-TL250V or
252276 ! 3.15A-SE-TL250V <O>
F903 252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V,Fuse <O>
P101 2047151512 NCFC7-151512,Flexible cable
P7502 2045102012 NCFC5-102012,Flexible cable
