Onkyo TX-SR501/E - Page 56

CIRCUIT NO. PART NO.
DESCRIPTION
Sockets
P902 25051571 ! NSCT-2P1358 <D>
P902 25051572 ! NSCT-2P1359 <P/T/Q>
P902 25052115 ! NSCT-2P2013 <A>
P902 25052664 ! NSCT-2P2560 <R>
P931A 25051230 NSCT-5P1020
Plu
g
P901A 25055675 or ! NPLG-2P631 or
25056028 ! NPLG-2P0978
Secondar
y
terminal PC board
(
NAPS-7846-1A/1B/1C/1D/1E/1F
)
CIRCUIT NO. PART NO.
DESCRIPTION
JL6951B,JL6952B 25051109 NSCT-5P896,Wire holder
V
ideo circuit PC board
(
NAVD-7847-1A/1B/1C/1D/1E/1F
)
CIRCUIT NO. PART NO.
DESCRIPTION
ICs
Q203 22241759 LA7956
Q212,Q213 22241759 LA7956
Q281 222740046R2 74HCU04F
Photo cou
p
lers
U281,U282 24120101 TORX179L
Transistors
Q201,Q202 2213631 or RN1241-A or
Q207,Q208 2213632 RN1241-B
Q204,Q209 2215995 or KTA1267-GR or
2213354 2SA933S-R
Q205,Q206 2215770 or KRA102M o
r
2213510 DTA114ES
Q210,Q211 2213631 or RN1241-A or
2213632 RN1241-B
Coils
L281,L282 233454K220 or NCH-1452 220K or
233526K220 NCH-1561 220K
L283 233454M022 or NCH-1452 022M o
r
233526K022 NCH-1561 022K
Ca
p
acitors
C201,C202 394680227 or CE04W50V-2.2M
(
VR
)
or
C204,C207 394780227 CE04W50V2.2M
(
SC
)
,Elect.
C203,C205 394644717 or CE04W16V-470M
(
VR
)
or
C211,C215 394744717 CE04W16V470M
(
SC
)
,Elect.
C209,C213 394680227 or CE04W50V-2.2M
(
VR
)
or
C217,C218 394780227 CE04W50V2.2M
(
SC
)
,Elect.
C221,C223 394644707 or CE04W16V-47M
(
VR
)
or
C225 394744707 CE04W16V47M
(
SC
)
,Elect.
C285 394624707 or CE04W6.3V-47M
(
VR
)
or
394624707 CE04W6.3V-47M
(
VR
)
,Elect.
Terminals
P201 25045729 NPJ-10PDBY517
P202 25045727 NPJ-15PDBY515
P281 25045473 NPJ-1PDBL291
P282 25045696 LGY2502-0200C
Socket
P206B 25051240 NSCT-15P1030
Plu
g
P253A 25055236 NPLG-5P220
Thermal detector PC board
(
NAETC-7849-1A/1B/1C/1D/1E/1F
)
CIRCUIT NO. PART NO.
DESCRIPTION
R6380 4000153 PTH9M04BF222TS2F333,Thermistor
JL6402B 25051087 NSCT-3P874,Socket
R6381 4000150 PTH9M04BC222TS2F333,Thermistor <O>
<D>:120V model only NOTE: THE COMPONENTS IDENTIFIED BY MARK !
<P>:European model only ARE CRITICAL FOR RISK OF FIRE AN
D
<T>:Worldwide model only ELECTRIC SHOCK. REPLACE ONLY WITH
<A>:Australian model only PART NUMBER SPECIFIED.
<R>:Chinese model only
<K>:Korean model only CAUTION: Replacement for transistor of mark *, if necessa
r
<Q>:Hong Kong model onl
y
must be made from the same beta group (
h
FE) a
s
<O>:Except 120V model the original type
.
Page 56
