Onkyo TX-SR501/E - Page 55

CIRCUIT NO. PART NO.
DESCRIPTION
Resistors
R6040~R6045 5210258 N06HR1KBC,Trimmin
g
R6070~R6075 415471014 R25J-100,NF carbon
R6080~R6085 415470224 R25J-2.2,NF carbon
R6090~R6095 415470224 R25J-2.2,NF carbon
R6100~R6105 4800071, RSS2WK-0.22,
4000131 or RGC22-0.22 OHMK o
r
4500027 MPC708-2WK-0.22,Metal
p
late
R6230~R6235 453630824 RNU1WCJ-8.2,Metal
R6604,R6605 453530824 RNU1/2WCJ-8.2,Metal
R6850,R6851 443523914 RS1/2WBJ-390,Metal oxide
Rela
y
s
RL6901,RL6902 25065561, NRL-1P5A-DC12-127,
25065508, NRL-1P10A-DC12-093,
25065515 or NRL-1P5A-DC12-096 or
25065526 NRL-1P5A-DC12-102
Fuse holders
F6901A,F6901B 25052133 ! NSCT-1P2031
F6902A,F6902B 25052133 ! NSCT-1P2031
Sockets
JL6402A 25051087 NSCT-3P874
JL6803A,JL6804A 25051110 NSCT-6P897
JL6805A 25051108 NSCT-4P895
JL6951A,JL6952A 25051109 NSCT-5P896
Plu
g
s
P6000~P6005 25056010 NPLG-5P0960
P6011 25056015 NPLG-10P0965
P6080~P6085 25055038 NPLG-2P29
P6301 25055042 NPLG-3P32
P6931 25055805 NPLG-16P761
P931 25055701 NPLG-5P657
Bar
C6901A 27141817
(
BUS
)
Label
F6901C 29362800 T8AL250V,Fuse <O>
Power switch PC board
(
NASW-7843-1B/1D/1E/1F
)
CIRCUIT NO. PART NO.
DESCRIPTION
S906 25035702 ! NPS-121-L665P,Switch <P/T/R/Q/K>
Primar
y
circuit PC board
(
NAPS-7845-1A/1B/1C/1D/1E/1F
)
CIRCUIT NO. PART NO.
DESCRIPTION
Power transforme
r
T902 2301381 ! NPT-1358D <D>
T902 2301382 ! NPT-1358P <P/A>
T902 2301383 ! NPT-1358DG <T/R/Q/K>
Diodes
D921~D924 22380260 or RL1N4003 or
22380035 GP104003E
D925 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Ca
p
acitors
C901 3500196S ! RE275V-103M,IS
C902 3300030 ! DE1307E472M-KH,IS <O>
C922 394662217 CE04W35V-220M
(
VR
)
,Elect.
Resistors
R901 4000206 or ! RD1/2SPH-3.3M o
r
431533355 ! RC1/2GFKUL-3.3M, Solid <D>
R924 443528204 RS1/2WBJ-82,Metal oxide
Rela
y
RL901 25065561, ! NRL-1P5A-DC12-127,
25065508, ! NRL-1P10A-DC12-093,
25065515 or ! NRL-1P5A-DC12-096 or
25065526 ! NRL-1P5A-DC12-102
Switch
S902 25065437 ! NSS-22157P,Volta
g
e <T/R/Q>
Fuse holders
F901A,F901B 25052133 ! NSCT-1P2031 <D/T/R/Q>
F902A,F902B 25052133 ! NSCT-1P2031 <O>
F903A,F903B 25052133 ! NSCT-1P2031 <O>
Page 55
