Onkyo TX-SR501/E - Page 54

Power am
p
lifier PC board
(
NAAF-7842-1A/1B/1C/1D/1E/1F
)
CIRCUIT NO. PART NO.
DESCRIPTION
Transistors
Q6010~Q6015 2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Q6020~Q6025 2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Q6030~Q6035 2203434 or KTD2061-Y or
2203010 2SC5171
Q6040~Q6045 2203424 or KTB1369-Y or
2203000 2SA1930
Q6070~Q6075 2215896, KTC3200-BL,
2210755, 2SC1775A-E,
2210756, 2SC1775A-F,
2211732, 2SC1845-F,
2211733 or 2SC1845-E or
2215895 KTC3200-GR
Q6303 2215995, KTA1267-GR,
2213354 or 2SA933S-R or
2213355 2SA933S-S
Q6313 2215995, KTA1267-GR,
2213354 or 2SA933S-R or
2213355 2SA933S-S <O>
Q6601~Q6603 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Q6701,Q6702 2215896, KTC3200-BL,
2210755, 2SC1775A-E,
2210756, 2SC1775A-F,
2211732, 2SC1845-F,
2211733 or 2SC1845-E or
2215895 KTC3200-GR
Q6703 2215885, KTA1268-GR,
2211792, 2SA992-F,
2211793 or 2SA992-E or
2215886 KTA1268-BL
Q6901 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Q921 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D6000~D6005 223163, 1SS133,
D6010~D6015 223205 or 1SS270A or
D6306,D6307 223222 WG713A
D6701,D6702 223163, 1SS133,
D6906 223205 or 1SS270A or
223222 WG713A
D6703,D6704 224470512 MTZJ5.1B
D6714 224470512 MTZJ5.1B <O>
D6903,D6904 22380130, D5SBA20,
22380038 or RBV602 or
22380274 RS603M-B42
Ca
p
acitors
C6040~C6045 394684707 CE04W50V-47M
(
VR
)
,Elect.
C6050~C6055 374722234 ECQ-B50V-223J,Plastic film
C6230~C6235 374724734 ECQ-V50V-473J,Plastic film
C6701,C6706 394621017 or CE04W6.3V-100M
(
VR
)
or
394721017 CE04W6.3V100M
(
SC
)
,Elect.
C6704 394680107 or CE04W50V-1M
(
VR
)
or
394780107 CE04W50V1.0M
(
SC
)
,Elect.
C6708 374722234 ECQ-B50V-223J,Plastic film
C6716 394621017 CE04W6.3V-100M
(
VR
)
,Elect. <O>
C6901 3504351 CE69W56V10000M,Elect.
C6902 3504351 CE69W56V10000M,Elect.
C6903 374721044 ECQ-B50V-104J,Plastic film
C6904,C6905 374723344 ECQ-V50V-334J,Plastic film
C6906,C6907 374721044 ECQ-B50V-104J,Plastic film
Page 54
