Onkyo TX-SR501/E - Page 53

CIRCUIT NO. PART NO.
DESCRIPTION
Terminal
P241 25045731 NPJ-9PDGLR519
Sockets
P242A 25052216 NSCT-20P2113
P243B 25051526 NSCT-4P1313
Constant volta
g
e circuit PC board
(
NAETC-7833-1A/1B
)
CIRCUIT NO. PART NO.
DESCRIPTION
IC
Q6931 222780565JRC 78M56
(
NJM78M56FA
)
Diodes
D6932,D6933 22380260 or RL1N4003 or
D6932 or 22380035 GP104003E
Ca
p
acitors
C6931 394651027 or CE04W25V-1000M
(
VR
)
or
394751027S CE04W25V1000M
(
SC
)
,Elect.
C6933 394641007 or CE04W16V-10M
(
VR
)
or
394741007 CE04W16V10M
(
SC
)
,Elect.
Resistor
R6935 441721214 RS2WBJ-120,Metal oxide
Sockets
JL9501A 25051111 NSCT-7P898
P410A 25051236 NSCT-11P1026
P411A 25051235 NSCT-10P1025
P6931A 25051527 NSCT-16P1314
P7503B 25052241, NSCT-8P2138,
25051312, NSCT-8P1101,
25051852 or NSCT-8P1639 or
25052054 NSCT-8P1841
Secondar
y
circuit PC board
(
NAPS-7834-1A/1B
)
CIRCUIT NO. PART NO.
DESCRIPTION
Resistors
R9501 453530104 RNU1/2WCJ-1,Metal
R9502 453534794 RNU1/2WCJ-0.47,Metal
R9503 453532294 RNU1/2WCJ-0.22,Metal
R9521 453530394 RNU1/2WCJ-3.9,Metal <D>
453530334 RNU1/2WCJ-3.3,Metal <O>
Socket
JL9501B 25051111 NSCT-7P898
S
p
eaker terminal PC board ass'
y
(
NAETC-7835-1A/1B
)
CIRCUIT NO. PART NO.
DESCRIPTION
Diodes
D6600,D6601 223163, 1SS133,
D6604 223205 or 1SS270A or
223222 WG713A
Coils
L6800~L6805 231176S S-1.3C <O>
Ca
p
acitors
C6600,C6604 374721034 ECQ-B50V-103J,Plastic film
C6840~C6845 374722224 ECQ-B50V-222J,Plastic film <O>
Rela
y
s
RL6600,RL6601 25065563, NRL-2P5A-DC24-129,
RL6603,RL6604 25065517 or NRL-2P5A-DC24-098 or
25065586 NRL-2P5A-DC24-142
Terminals
P6800 25060347 NTM-4PDMN278 <D>
P6800 25060316 NTM-4PDMN247 <O>
P6801 25060317 NTM-4PDML248
P6802 25060348 NTM-8PDMN279 <D>
P6802 25060349 NTM-8PDMN280 <O>
Sockets
JL6803B~JL6805B 25050270 NSCT-6P98
Connector PC board
(
NAETC-7838-1A/1B
)
CIRCUIT NO. PART NO.
DESCRIPTION
P206A 25055711 NPLG-15P667,Plu
g
P243A 25055804 NPLG-4P760,Plu
g
P801B 25051240 NSCT-15P1030,Socket
