CIRCUIT NO. PART NO.
DESCRIPTION
Sockets
P101 25052211 or NSCT-15P2108 or
25052024 NSCT-15P1811
P306 2009990825UL NSAS-26P1207
P7502B 25052576R2 NSCT-10P2473
Plu
g
s
P261A 25055133 NPLG-3P117
P410B 25055707 NPLG-11P663
P411B 25055706 NPLG-10P662
P412B 25055704 NPLG-8P660
P801 25055711 NPLG-15P667
Heat sink
Q6402B 27160526 RAD-183
Screws
Q6402A,Q6405A 82143010 3P+10FN
(
BC
)
,Pan head
Q6406A 82143010 3P+10FN
(
BC
)
,Pan head
Driver circuit PC board
(
NAAF-7830-1A/1B
)
CIRCUIT NO. PART NO.
DESCRIPTION
Transistors
Q5000~Q5005 2215896, * KTC3200-BL,
Q5010~Q5015 2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
2211733 * 2SC1845-E
Q5030~Q5035 2215844, KTA1024-Y,
2211353, 2SA949-O,
2211354 or 2SA949-Y or
2215843 KTA1024-O
Q5040~Q5045 2215854, KTC3206-Y,
2211633, 2SC2229-O,
2211634 or 2SC2229-Y or
2215853 KTC3206-O
Q5050~Q5055 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D5000~D5005 224470562 MTZJ5.6B
Ca
p
acitors
C5000~C5005 374721015 ECQ-B50V-101K,Plastic film
C5010~C5015 393342207 CE04W16V-22M
(
VX
)
,Elect.
C5020~C5025 394681007 CE04W50V-10M
(
VR
)
,Elect.
C5040,C5041 393342217 CE04W16V-220M
(
VX
)
,Elect.
C5042~C5045 393342217 CE04W16V-220M
(
VX
)
,Elect.
C5050~C5055 394684707 CE04W50V-47M
(
VR
)
,Elect.
C5100~C5105 394671007 CE04W63V-10M
(
VR
)
,Elect.
C5110~C5115 394671007 CE04W63V-10M
(
VR
)
,Elect.
Resistors
R5160~R5165 415471214 R25J-120,NF carbon
R5170~R5175 415471214 R25J-120,NF carbon
R5180~R5185 415471004 R25J-10,NF carbon
R5190~R5195 415471004 R25J-10,NF carbon
Sockets
P6000A~P6005A 25052288 NSCT-5P2185
P6011A 25052293 NSCT-10P2190
Plu
g
P306A 25055376 NPLG-12P359
Bus bar
P5001 27141867 BBL40
Com
p
onent video PC board
(
NAVD-7831-1A/1B
)
CIRCUIT NO. PART NO.
DESCRIPTION
Transistor
Q241 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diode
D241 223163 or 1SS133 or
223205 1SS270A
Rela
y
s
RL241,RL242 25065610 NRL-2P1A-DC4.5-156
