Onkyo TX-SR501/E - Page 51

CIRCUIT NO. PART NO.
DESCRIPTION
Ca
p
acitors
C101,C103 394780337 or CE04W50V3.3M
(
SC
)
or
394680337 CE04W50V-3.3M
(
VR
)
,Elect.
C181 394780227 or CE04W50V2.2M
(
SC
)
or
394680227 CE04W50V-2.2M
(
VR
)
,Elect. <P>
C184 354724709T CE04W6.3V-47M,Elect. <P>
C300,C301 374721015 ECQ-B50V-101K,Plastic film <D>
374724714 ECQ-B50V-471J,Plastic film <O>
C329~C334 393341007 CE04W16V-10M
(
VX
)
,Elect.
C335,C336 373043324R2 ECHU16V-332J,Chi
p
film
C338,C340 373045634R2 ECHU16V-563J,Chi
p
film
C347,C348 394741017 or CE04W16V100M
(
SC
)
or
394641017 CE04W16V-100M
(
VR
)
,Elect.
C349 393341007 CE04W16V-10M
(
VX
)
,Elect.
C353,C354 393344707 CE04W16V-47M
(
VX
)
,Elect.
C358 393344707 CE04W16V-47M
(
VX
)
,Elect.
C359,C362 394741007 or CE04W16V10M
(
SC
)
or
394641007 CE04W16V-10M
(
VR
)
,Elect.
C363,C364 393341007 CE04W16V-10M
(
VX
)
,Elect.
C6401 374721044 ECQ-B50V-104J,Plastic film
C6404,C6406 394741007 or CE04W16V10M
(
SC
)
or
C6410,C6412 394641007 CE04W16V-10M
(
VR
)
,Elect.
C7001 3000078, DX-5R5L104,
3000120 or FMC0H104Z o
r
3000121 SCDA5R5104A,Su
p
er
C7002,C7005 394721017 or CE04W6.3V100M
(
SC
)
or
394621017 CE04W6.3V-100M
(
VR
)
,Elect.
C7004 394780107 or CE04W50V1.0M
(
SC
)
or
394680107 CE04W50V-1M
(
VR
)
,Elect.
C7011,C7012 394744707 or CE04W16V47M
(
SC
)
or
C7015 394644707 CE04W16V-47M
(
VR
)
,Elect.
C706,C716 394721017 or CE04W6.3V100M
(
SC
)
or
394621017 CE04W6.3V-100M
(
VR
)
,Elect.
C801,C810 394744707 or CE04W16V47M
(
SC
)
or
394644707 CE04W16V-47M
(
VR
)
,Elect.
C806 394724717 or CE04W6.3V470M
(
SC
)
or
394624717 CE04W6.3V-470M
(
VR
)
,Elect.
C809,C820 394741007 or CE04W16V10M
(
SC
)
or
394641007 CE04W16V-10M
(
VR
)
,Elect.
C810 394744707 or CE04W16V47M
(
SC
)
or
394644707 CE04W16V-47M
(
VR
)
,Elect.
C822 394722217 or CE04W6.3V220M
(
SC
)
or
394622217 CE04W6.3V-220M
(
VR
)
,Elect.
C832~C837 393341007 CE04W16V-10M
(
VX
)
,Elect.
C841 373048224R2 ECHU16V-822J,Chi
p
film
C849 373041534R2 ECHU16V-153J,Chi
p
film
C852,C853 374721524 ECQ-B50V-152J,Plastic film
C854 393341007 CE04W16V-10M
(
VX
)
,Elect.
C855 393344707 CE04W16V-47M
(
VX
)
,Elect.
C856~C860 393341007 CE04W16V-10M
(
VX
)
,Elect.
C863 393341007 CE04W16V-10M
(
VX
)
,Elect.
C9501~C9503 374721044 ECQ-B50V-104J,Plastic film
C9505 394762227 or CE04W35V2200M
(
SC
)
or
394662227 CE04W35V-2200M
(
VR
)
,Elect.
C9506 394764717 or CE04W35V470M
(
SC
)
or
394664717 CE04W35V-470M
(
VR
)
,Elect.
C9507 394762217 or CE04W35V220M
(
SC
)
or
394662217 CE04W35V-220M
(
VR
)
,Elect.
C9508 394744727 or CE04W16V4700M
(
SC
)
or
394644727 CE04W16V-4700M
(
VR
)
,Elect.
C9510 394672217 CE04W63V-220M
(
VR
)
,Elect.
Resistors
R6402 442521004 RS1/2WBJ-10,Metal oxide
R6403 442523304 RS1/2WBJ-33,Metal oxide
R6407 452630334 RNU1WCJ-3.3,Metal
R6410 453530224 RNU1/2WCJ-2.2,Metal
R9506 443522204 RS1/2WBJ-22,Metal oxide
Terminals
P301,P304 25045571 or NPJ-6PDRW386 or
25045300 NPJ-6PDBL159
P305 25045697 NPJ-6PWRLGGP493
P351 25045720 NPJ-1PDP510
Page 51
