Onkyo TX-SR501/E - Page 59

REF.NO. PART NO. DESCRIPTION
U24 1A970545-1A NAPS-7845-1A,Primar
y
circuit PC board ass'
y
<D>
1A970545-1B
NAPS-7845-1B,Primar
y
circuit PC board ass'
y
<P>
1A970545-1C NAPS-7845-1C,Primar
y
circuit PC board ass'
y
<A>
1A970545-1D NAPS-7845-1D,Primar
y
circuit PC board ass'
y
<R>
1A970545-1E NAPS-7845-1E,Primar
y
circuit PC board ass'
y
<T/Q>
1A970545-1F NAPS-7845-1F,Primar
y
circuit PC board ass'
y
<K>
U25 1A970546-1A NAPS-7846-1A,Secondar
y
terminal PC board ass'
y
<D>
1A970546-1B NAPS-7846-1B,Secondar
y
terminal PC board ass'
y
<P>
1A970546-1C NAPS-7846-1C,Secondar
y
terminal PC board ass'
y
<A>
1A970546-1D NAPS-7846-1D,Secondar
y
terminal PC board ass'
y
<R>
1A970546-1E NAPS-7846-1E,Secondar
y
terminal PC board ass'
y
<T/Q>
1A970546-1F NAPS-7846-1F,Secondar
y
terminal PC board ass'
y
<K>
U26 1A970547-1A NAVD-7847-1A,Video circuit PC board ass'
y
<D>
1A970547-1B NAVD-7847-1B,Video circuit PC board ass'
y
<P>
1A970547-1C NAVD-7847-1C,Video circuit PC board ass'
y
<A>
1A970547-1D NAVD-7847-1D,Video circuit PC board ass'
y
<R>
1A970547-1E NAVD-7847-1E,Video circuit PC board ass'
y
<T/Q>
1A970547-1F NAVD-7847-1F,Video circuit PC board ass'
y
<K>
U28 1A970549-1A NAETC-7849-1A,Thermal det. PC board ass'
y
<D>
1A970549-1B NAETC-7849-1B,Thermal det. PC board ass'
y
<P>
1A970549-1C NAETC-7849-1C,Thermal det. PC board ass'
y
<A>
1A970549-1D NAETC-7849-1D,Thermal det. PC board ass'
y
<R>
1A970549-1E NAETC-7849-1E,Thermal det. PC board ass'
y
<T/Q>
1A970549-1F NAETC-7849-1F,Thermal det. PC board ass'
y
<K>
U30 1A970551-1F NAETC-7851-1F,AC outlet terminal PC board ass'
y
<K>
U31 240146, FAE385-A02F,
240134A or TFCE1U114B or
240138A ENG06501QR,Tuner unit <D>
240147, FAE485-E02F,
240135 or TFCE1E512A or
240139A ENG07501QR,Tuner unit <O>
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (h
FE) as
the original type.
<B>:Black model only
<S>:Silver model only
<G>:Golden mpdel only
<D>:120V model only
<P>:European model only
<T>:Worldwide model only
<A>:Australian model only
<R>:Chinese model only
<C>:Canadian model only
<K>:Korean model only
<Q>:Hongkong model only
<O>:Except 120V model
Page 59
