Onkyo TX-SR600/E - Page 33

PRIMARY CIRCUIT PC BOARD (NAPS-7484-1A/1B/1C/1D/1E/1F)
CIRCUIT NO. PART NO. DESCRIPTION
Transistor
Q921 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D921~D924 22380260 or RL1N4003 or
22380035 GP104003E
D925 223163, 1SS133,
223205 or 1SS270A or
Power transformer
T902 2301381 NPT-1358D <D>
2301382 NPT-1358P <P/Q>
2301383 NPT-1358DG <T/R/Q/K>
Capacitors
C901 3500196S ! RE275V-103M,IS
C922 394662217 220uF,35V,Elect.
C923 374722234 0.022uF+/-5%,50V,Plastic
Resistors
R901 4000206S ! RD1/2SPH-3.3M,Solid <D>
R924 443528204 82ohm+/-5%,1/2W,Metal oxide
AC outlet
P902 25051126 ! NSCT-4P913 <D>
P902 25051125 ! NSCT-4P912 <P/T/Q>
P902 25052115 ! NSCT-2P2013 <A>
P902 25052381 ! NSCT-2P2278 <R>
Relay
RL901 25065561, ! NRL-1P5A-DC12-127,
25065508, ! NRL-1P10A-DC12-093,
25065515 or ! NRL-1P5A-DC12-096 or
25065526 ! NRL-1P5A-DC12-102
Fuse holders
F901A,F901B 25052133 ! NSCT-1P2031<D/R/T/Q>
F902A,F902B 25052133 ! NSCT-1P2031<O>
F903A,F903B 25052133 ! NSCT-1P2031 <O>
Switch
S902 25065437 ! NSS-22157P <T/Q/R>
Socket
P931A 25051230 NSCT-5P1020
Plug
P901A 25055675 or ! NPLG-2P631 or
25056028 ! NPLG-2P0978
CONNECTOR PC BOARD (NAETC-7486-1A/1B/1C/1D/1E/1F)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q2225 2213290 DTC114ES
Q2231,Q2232 2215770 or KRA102M or
Q2234,Q2236 2213510 DTA114ES
Q2237 2215770 or KRA102M or
2213510 DTA114ES
Sockets
P105A 25051237 NSCT-12P1027
P106A 25051526 NSCT-4P1313
P107A 25051240 NSCT-15P1030
P205A 25055709 NPLG-13P665
P207A 25055708 NPLG-12P664
POWER SWITCH PC BOARD (NASW-7487-1B/1C/1D/1E/1F)
CIRCUIT NO. PART NO. DESCRIPTION
Capacitors
C902 3300030 ! DE1307E472M-KH,IS,IS <O>
Switch
S906 25035702 ! NPS-121-L665P <O>
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
<D>: 120V model only
<P>: European model only
<T>: Worldwide model only
<K>: Korean model only
<A>: Australian model only
<R>: Chinese model only
<Q>: Hongkong model only
<O>: Except 120V model
!
!
!
TX-SR600/E
PRINTED CIRCUIT BOARD-PARTS LIST 6
