Onkyo TX-SR603E - Page 113

11/42 PAGE
PCB1
RL2201 or RELAY NRL-2P2A-DC4.5-173 ( 1) 25065658
PCB1
RL2202 RELAY NPL-2P1A-DC4.5-169 1 25065645
PCB1
RL2202 or RELAY NRL-2P2A-DC4.5-173 ( 1) 25065658
PCB1
RL2203 RELAY NPL-2P1A-DC4.5-169 1 25065645
PCB1
RL2203 or RELAY NRL-2P2A-DC4.5-173 ( 1) 25065658
PCB1
RL2204 RELAY NPL-2P1A-DC4.5-169 1 25065645
PCB1
RL2204 or RELAY NRL-2P2A-DC4.5-173 ( 1) 25065658
PCB1
RL2205 RELAY NPL-2P1A-DC4.5-169 1 25065645
PCB1
RL2205 or RELAY NRL-2P2A-DC4.5-173 ( 1) 25065658
PCB1
P2001 PIN JACK NPJ-10PDBY621 1 25045842
PCB1
P2001 or PIN JACK NPJ-10PDBY478 ( 1) 25045681
PCB1
P2002 PIN JACK NPJ-10PDBY621 1 25045842
PCB1
P2002 or PIN JACK NPJ-10PDBY478 ( 1) 25045681
PCB1
P2003 PIN JACK NPJ-10PDBY621 1 25045842
PCB1
P2003 or PIN JACK NPJ-10PDBY478 ( 1) 25045681
PCB1
P2004A SOCKET NSCT-13P2193 1 25052296
PCB1
P2005A SOCKET NSCT-13P2193 1 25052296
PCB1
P2007 PIN JACK NPJ-5PDBY622 1 25045843
PCB1
P2007 or PIN JACK NPJ-5PDBY479 ( 1) 25045682
PCB1
P2201 PIN JACK NPJ-9PDGLRGLRGLR563 1 25045781
PCB1
P2201 or PIN JACK NPJ-9PDGLR519 ( 1) 25045731
PCB1
P2202 PIN JACK NPJ-3PDGLR623 1 25045844
PCB1
E2001 TRM(SCREW) NEGITANSI M3 1 25065425
PCB1
JL2006A WIRE HOL NSCT-5P896 1 25051109
U02 DISPLAY PC BOARD (NADIS-8513-1N/P/Q)
U03 DSP PC BOARD (NADG-8514-1N/P/Q)
U04 SWITCH PC BOARD (NASW-8515-1N/P/Q)
U05 HEADPHONE JACK PC BOARD (NASW-8516-1N/P/Q)
U06 FRONT OPT PC BOARD (NAETC-8517-1N/P/Q)
U07 IR IN TERMINAL PC BOARD (NAETC-8518-1N/P/Q)
U08 HOLDER PC BOARD (NAETC-8520-1N/P/Q)
CIRCUIT N
O
NAME DESCRIPTION Q'TY PART NO REMARKS
PCB2
U131 PHT CP TORX177L 1 24120127
PCB2
U132 PHT CP TORX177L 1 24120127
PCB2
U133 PHT CP TORX177L 1 24120127
PCB2
U134 PHT CP TOTX177L 1 24120126
PCB2
U821 REMO SENS GP1UM281XKVFH=16MM 1 241361
PCB2
U883 PHT CP TORX177L 1 24120127
PCB2
Q111 IC BU1924FS 1 22242120R2 <PP>
PCB2
Q121 PHT CP PC817X 1 24120080
PCB2
Q122 TR UNR2211 1 2217130R2
PCB2
Q122 or TR RN1402 ( 1) 2214470R2
PCB2
Q122 or TR KRC102S ( 1) 2216190R2
PCB2
Q123 TR UNR2211 1 2217130R2
PCB2
Q123 or TR RN1402 ( 1) 2214470R2
PCB2
Q123 or TR KRC102S ( 1) 2216190R2
PCB2
Q126 TR 2SB1068-U 1 2212855
PCB2
Q126 or TR 2SB1068-K ( 1) 2212853
PCB2
Q127 TR UNR2211 1 2217130R2
PCB2
Q127 or TR RN1402 ( 1) 2214470R2
PCB2
Q127 or TR KRC102S ( 1) 2216190R2
PCB2
Q131 IC 74HCU04F 1 222740046R2
PCB2
Q151 IC TC74VHC541FT 1 22274541ER2TO
PCB2
Q151 or IC SN74AHC541PWR ( 1) 22274541IR2TI
PCB2
Q152 IC TC74HCT7007AF 1 222740077R2TO
PCB2
Q171 IC TC7WU04FU 1 22240935R2
PCB2
Q201 IC CS494003CQZ 1 22242039R3
PCB2
Q281 IC MX26LV040TC 1 W0037R301456M100
PCB2
Q282 IC K4S161622H-UC60 1 22242152R2
PCB2
Q282 or IC IC42S16100 ( 1) 22242123R2
PCB2
Q401 IC NJM4580M-D 1 22241448R2
PCB2
Q402 IC NJM4580M-D 1 22241448R2
PCB2
Q403 IC NJM4580M-D 1 22241448R2
PCB2
Q404 IC NJM4580M-D 1 22241448R2
PCB2
Q421 IC CS42518-CQZR-D 1 22242229R2
PCB2
Q501 IC NJM4580M-D 1 22241448R2
PCB2
Q502 IC NJM4580M-D 1 22241448R2
PCB2
Q503 IC NJM4580M-D 1 22241448R2
PCB2
Q701 IC M30624MHP-253FPU0 1 22242251R3
PCB2
Q703 TR UNR2213 1 2217140R2
PCB2
Q703 or TR RN1404 ( 1) 2214490R2
PCB2
Q703 or TR KRC104S ( 1) 2216210R2
PCB2
Q705 TR UNR2111 1 2217110R2
