Onkyo TX-SR700/E

DRIVER CIRCUIT PC BOARD (NAAF-7483-1N/1O)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5000~Q5002 2211733, * 2SC1845-E,
Q5010~Q5012 2210755 or * 2SC1775A-E or
2210756, * 2SC1775A-F,
Q5003~Q5005 2215896, * KTC3200-BL,
Q5013~Q5015 2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
2211733 * 2SC1845-E
Q5020~Q5022 2211793 or 2SA992-E or
2211792 2SA992-F
Q5030~Q5032 2211354 or 2SA949-Y or
2211353 2SA949-O
Q5033~Q5035 2215844, KTA1024-Y,
2211353, 2SA949-O,
2211354 or 2SA949-Y or
2215843 KTA1024-O
Q5040~Q5042 2211634 or 2SC2229-Y or
2211633 2SC2229-O
Q5043~Q5045 2215854, KTC3206-Y,
2211633, 2SC2229-O,
2211634 or 2SC2229-Y or
2215853 KTC3206-O
Q5050~Q5052 2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Q5053~Q5055 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D5000~D5005 224470562 MTZJ5.6B
Capacitors
C5000~C5005 374721015 100pF+/-10%,50V,Plastic
C5010~C5015 393341017 100uF,16V,Elect.
C5020~C5025 394681007 10uF,50V,Elect.
C5040~C5045 393342217 220uF,16V,Elect.
C5050~C5055 394684707 47uF,50V,Elect.
C5100~C5105 394691007 10uF,100V,Elect.
C5110~C5115 394691007 10uF,100V,Elect.
Resistors
R5120~R5122 415474714 470ohm+/-5%,1/4W,NF carbon
R5160~R5165 415471214 120ohm+/-5%,1/4W,NF carbon
R5170~R5175 415471214 120ohm+/-5%,1/4W,NF carbon
R5180~R5185 415471004 10ohm+/-5%,1/4W,NF carbon
R5190~R5195 415471004 10ohm+/-5%,1/4W,NF carbon
Sockets
P6000B~P6005
B
25052288 NSCT-5P2185
P6011B 25052293 NSCT-10P2190
Plug
P404A 25055156 NPLG-12P140
Holders
P5000,P5002 27190540-1 Clamp
P5003 27190540-1 Clamp
PRIMARY CIRCUIT PC BOARD (NAPS-7484-1N/1O/1P/1Q/1R/1U)
CIRCUIT NO. PART NO. DESCRIPTION
Transistor
Q921 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D921~D924 22380260 or RL1N4003 or
22380035 GP104003E
D925 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Power transformer
T902 2301381 ! NPT-1358D <D>
2301382 ! NPT-1358P <P>
2301383 ! NPT-1358DG <T/R/K>
Capacitors
C901 3500196S ! RE275V-103M,IS
C922 394662217 220uF,35V,Elect.
C923 374722234 0.022uF+/-5%,50V,Plastic
Resistors
R901 4000206S ! RD1/2SPH-3.3M,Solid <D>
R924 443528204 82ohm+/-5%,1/2W,Metal oxide
AC outlet
P902 25051126 ! NSCT-4P913 <D>
P902 25051125 ! NSCT-4P912 <P/T>
P902 25052115 ! NSCT-2P2013 <A>
P902 25052381 ! NSCT-2P2278 <R>
Relay
RL901 25065584 or ! NRL-1P10A-DC12-140 or
25065516 ! NRL-1P10A-DC12-097
Fuse holders
F901A,F901B 25052133 ! NSCT-1P2031<D/R/T>
F902A,F902B 25052133 ! NSCT-1P2031<O>
F903A,F903B 25052133 ! NSCT-1P2031 <O>
Fuse labels
F901C 29362241 10A/125V <D/R/T>
F902C 29361938 T5AL250V <O>
Switch
S902 25065437 ! NSS-22157P <T/R>
Socket
P931A 25051230 NSCT-5P1020
Plug
P901A 25055675 or ! NPLG-2P631 or
25056028 ! NPLG-2P0978
CONNECTOR PC BOARD (NAETC-7486-1N/1O/1P/1Q/1R/1U)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q2031,Q2032 2215960 or KRC102M or
Q2225 2213290 DTC114ES
Q2226 2212855 or 2SB1068-U or
2212853 2SB1068-K
Q2231,Q2232 2215770 or KRA102M or
Q2234,Q2236 2213510 DTA114ES
Q2233,Q2235 2215770 or KRA102M or
2213510 DTA114ES
Capacitors
C2031 394641017 100uF,16V,Elect.
C2032 374722234 0.022uF+/-5%,50V,Plastic
C2243 394644707 47uF,16V,Elect.
Themistors
R2247 4000195 RXE030
Sockets
P105A 25051241 NSCT-20P1031
P106A 25051526 NSCT-4P1313
POWER SWITCH PC BOARD (NASW-7487-1O/1P/1Q/1U)
CIRCUIT NO. PART NO. DESCRIPTION
Capacitors
C902 3300030 ! DE1307E472M-KH,IS <O>
Switch
S906 25035702 ! NPS-121-L665P <O>
P107A 25051240 NSCT-15P1030
P205A 25055712 NPLG-20P668
P207A 25055708 NPLG-12P664
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (h
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<P>: European model only
<T>: Worldwide model only
<K>: Korean model only
<A>: Australian model only
<R>: Chinese model only
<O>: Other models except
120V model
TX-SR700/E
PRINTED CIRCUIT BOARD-PARTS LIST 6
Page 47
