Onkyo TX-SR700/E

REF.NO. PART NO. DESCRIPTION
T901 2301587 ! NPT-1439D,Power transformer <D>
2301588 ! NPT-1439P,Power transformer <P/A>
2301589 ! NPT-1439DG,Power transformer <T/R/K>
U1 1A929560-1N NADG-7460-1N,Main circuit PC board ass'y <D>
1A929560-1O NADG-7460-1O,Main circuit PC board ass'y <P>
1A929560-1P NADG-7460-1P,Main circuit PC board ass'y <A/K>
1A929560-1Q NADG-7460-1Q,Main circuit PC board ass'y <T/R>
U2 1A929561-1N NADIS-7461-1N,Display circuit PC board ass'y <D>
1A929561-1O NADIS-7461-1O,Display circuit PC board ass'y <O>
U3 1A929562-1N NASW-7462-1N,Volume PC board ass'y <D>
1A929562-1O NASW-7462-1O,Volume PC board ass'y <O>
U4 1A929563-1N NAETC-7463-1N,Headphone terminal PC board ass'y <D>
1A929563-1O NAETC-7463-1O,Headphone terminal PC board ass'y <O>
U5 1A929564-1N NAVD-7464-1N,Video terminal PC board ass'y <D>
1A929564-1O NAVD-7464-1O,Video terminal PC board ass'y <O>
U6 1A929565-1N NAVD-7465-1N,Component video terminal PC board ass'y <D>
1A929565-1O NAVD-7465-1O,Component video terminal PC board ass'y <O>
U8 1A929567-1N NAVD-7467-1N,Front video PC board ass'y <D>
1A929567-1O NAVD-7467-1O,Front video PC board ass'y <O>
U11 1A929570-1N NADG-7470-1N,Front optical input PC board ass'y <D>
1A929570-1O NADG-7470-1O,Front optical input PC board ass'y <O>
U12 1A929571-1N NAETC-7471-1N,PC board for holder <D>
1A929571-1O NAETC-7471-1O,PC board for holder <O>
U14 1A929573-1N NAAF-7473-1N,Equalizer amplifier PC board ass'y <D>
1A929573-1O NAAF-7473-1O,Equalizer amplifier PC board ass'y <O>
U15 1A929574-1N NAAF-7474-1N,Power amplifier PC board ass'y <D>
1A929574-1O NAAF-7474-1O,Power amplifier PC board ass'y <O>
U16 1A929576-1N NAETC-7476-1N,Speaker terminal PC board ass'y <D>
1A929576-1O NAETC-7476-1O,Speaker terminal PC board ass'y <O>
U17 1A929577-1N NAPS-7477-1N,Secondary circuit PC board ass'y <D>
1A929577-1O NAPS-7477-1O,Secondary circuit PC board ass'y <O>
U18 1A929578-1N NAETC-7478-1N,Preoutput PC board ass'y <D>
1A929578-1O NAETC-7478-1O,Preoutput PC board ass'y <O>
U19 1A929579-1N NAETC-7479-1N,PC board for holder <D>
1A929579-1O NAETC-7479-1O,PC board for holder <O>
U20 1A929580-1N NAETC-7480-1N,Thermal detector PC board ass'y <D>
1A929580-1O NAETC-7480-1O,Thermal detector PC board ass'y <O>
U21 1A929581-1N NAETC-7481-1N,PC board for holder <D>
1A929581-1O NAETC-7481-1O,PC board for holder <O>
U23 1A929583-1N NAAF-7483-1N,Driver circuit PC board ass'y <D>
1A929583-1O NAAF-7483-1O,Driver circuit PC board ass'y <P>
1A929583-1P NAAF-7483-1P,Driver circuit PC board ass'y <A>
1A929583-1Q NAAF-7483-1Q,Driver circuit PC board ass'y <R>
1A929583-1R NAAF-7483-1R,Driver circuit PC board ass'y <T>
1A929583-1U NAAF-7483-1U,Driver circuit PC board ass'y <K>
REF.NO. PART NO. DESCRIPTION
U24 1A929584-1N NAPS-7484-1N,Primary circuit PC board ass'y <D>
1A929584-1O NAPS-7484-1O,Primary circuit PC board ass'y <P>
1A929584-1P NAPS-7484-1P,Primary circuit PC board ass'y <A>
1A929584-1Q NAPS-7484-1Q,Primary circuit PC board ass'y <R>
1A929584-1R NAPS-7484-1R,Primary circuit PC board ass'y <T>
1A929584-1U NAPS-7484-1U,Primary circuit PC board ass'y <K>
U26 1A929586-1N NAETC-7486-1N,Connector PC board ass'y <D>
1A929586-1O NAETC-7486-1O,Connector PC board ass'y <P>
1A929586-1P NAETC-7486-1P,Connector PC board ass'y <A>
1A929586-1Q NAETC-7486-1Q,Connector PC board ass'y <R>
1A929586-1R NAETC-7486-1R,Connector PC board ass'y <T>
1A929586-1U NAETC-7486-1U,Connector PC board ass'y <K>
U27 1A929587-1O NASW-7487-1O,Power switch PC board ass'y <P>
1A929587-1P NASW-7487-1P,Power switch PC board ass'y <A>
1A929587-1Q NASW-7487-1Q,Power switch PC board ass'y <R>
1A929587-1R NASW-7487-1R,Power switch PC board ass'y <T>
1A929587-1U NASW-7487-1U,Power switch PC board ass'y <K>
U28 1A929588-1O NAETC-7488-1O,PC board for holder <P>
1A929588-1P NAETC-7488-1P,PC board for holder <A>
1A929588-1Q NAETC-7488-1Q,PC board for holder <R>
1A929588-1R NAETC-7488-1R,PC board for holder <T>
1A929588-1U NAETC-7488-1U,PC board for holder <K>
U29 1A929589-1N NAPS-7489-1N,Terminal PC board ass'y <D>
1A929589-1O NAPS-7489-1O,Terminal PC board ass'y <P>
1A929589-1P NAPS-7489-1P,Terminal PC board ass'y <A>
1A929589-1Q NAPS-7489-1Q,Terminal PC board ass'y <R>
1A929589-1R NAPS-7489-1R,Terminal PC board ass'y <T>
1A929589-1U NAPS-7489-1U,Terminal PC board ass'y <K>
U31 1A929591-1N NAETC-7491-1N,PC board for holder <D>
1A929591-1O NAETC-7491-1O,PC board for holder <P>
1A929591-1P NAETC-7491-1P,PC board for holder <A>
1A929591-1Q NAETC-7491-1Q,PC board for holder <R>
1A929591-1R NAETC-7491-1R,PC board for holder <T>
1A929591-1U NAETC-7491-1U,PC board for holder <K>
U32 1A929592-1N NAETC-7492-1N,PC board for holder <D>
1A929592-1O NAETC-7492-1O,PC board for holder <P>
1A929592-1P NAETC-7492-1P,PC board for holder <A>
1A929592-1Q NAETC-7492-1Q,PC board for holder <R>
1A929592-1R NAETC-7492-1R,PC board for holder <T>
1A929592-1U NAETC-7492-1U,PC board for holder <K>
U33 1A929593-1U NAPS-7493-1U,AC outlet PC board ass'y <K>
U36 240138A, ENG06501QR,
240134A or TFCE1U114B or
240141 FAE350-A13F,Tuner unit <D>
240139A, ENG07501QR,
240135 or TFCE1E512A or
240142 FAE404-E13F,Tuner unit <O>
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<P>: European model only
<T>: 230-240 model only
<K>: Korean model only
<A>: Australian model only
<R>: Chinese model only
<O>: Other models except
120V model
TX-SR700/E
EXPLODED VIEW-PARTS LIST 2
TX-SR700/E
Page 5
