Onkyo TX-SR700/E - Exploded View-Parts List 1

REF.NO. PART NO. DESCRIPTION
1 27111271B Front bracket <B>
27111272B Front bracket <S>
27111273B Front bracket <G>
2 27212388 Front panel <B> <D>
27212389 Front panel <B> <A/T>
27212390 Front panel <B> <P>
27212391 Front panel <S>
27212392 Front panel <G>
3 28198778 Facet
4 838130088 3TTB+8B,Self-tapping screw
5 28135244 Badge <B>
28135245 Badge <S/G>
6 838430088 3TTB+8B(BC),Self-tapping screw
7 28326010 Knob, volume <B>
28326011 Knob, volume <S>
28326012 Knob, volume <G>
8 27122973A Rear panel <D>
27122974A Rear panel <P>
27122975A Rear panel <T>
27122976A Rear panel <A>
27122977A Rear panel <R>
27122978A Rear panel <K>
10 82143010 3P+10FN(BC),Pan head screw
11 27191130 ! Holder, outlet <R>
12 28325497A Knob,power <B>
28325499A Knob,power <S>
28325547A Knob,power <G>
14 27255004 CS-1U,Clip
16 28191957 Clear plate <B>
16 28191958 Clear plate <G/S>
18 87643010 W3*10F(BC),Flat washer
21 27100418A Chassis
22 27190693A KGLS-6RF,Holder
23 27190428A KGLS-10RF,Holder
24 27190266 KGLS-12RF,Holder
26 27190369 Holder
27 27300750 ! Bushing, cord
31 27160505 heat sink
32 801433 3SMS8W.SW+14B(BC),Special screw
33 830440089 4TTC+8C(BC),Self-tapping screw
34 28330135A Cap, screw
36 29110083 Tape, cloth
41 28184835 Top cover <B>
41 28184836 Top cover <S>
41 28184837 Top cover <G>
42 838930088 3TTB+8B(UN),Self-tapping screw
46 27175319B Leg
REF.NO. PART NO. DESCRIPTION
47 28141494 Cushion
51 260208 Wire tie
52 223025 AC262,Isolated sheet
F6901,F6902 252100 ! 10A-EAK,Fuse <O>
252196 ! 12A-UL/T-314,Fuse <D>
F901 252199 ! 10A-UL,Fuse <D/T/R>
F902 252078, ! 5A-SE-EAK,
252244 or ! 5A-SE-TL250V or
252278 ! 5A-SE-TL250V,Fuse <O>
F903 252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V,Fuse <O>
F9501 252160 or ! 2.5A-UL/T-237 or
252254 ! 2.5A-T/UL-ST2,Fuse <D>
252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V,Fuse <O>
P101 2047152522 NCFC7-152522,Flexible cable
P2602 2047071622 NCFC7-071622,Flexible cable
P2602 2047071622 NCFC7-071622,Flexible cable
P2602 2047071622 NCFC7-071622,Flexible cable
P6931 2047134512 NCFC7-134512,Flexible cable
P7501 2047113022 NCFC7-113022,Flexible cable
P7502 2047061522 NCFC7-061522,Flexible cable
P901 253332HIT or ! AS-UC-2 or
253333VOL ! AS-UC-2,Power supply cord <D>
253233KAW ! AS-CEE-2,Power supply cord <P/T/K>
253197HIT or ! AS-SAA or
253307VOL ! AS-SAA,Power supply cord <A>
253337HIT or ! AS-CCEE or
253338VOL ! AS-CCEE,Power supply cord <R>
P902A 25052665 ! NSCT-2P2561,AC outlet <K>
Q6050~Q6052 2202823 or * 2SC5200-O or
2202822 * 2SC5200-R,Transistor
Q6053~Q6055 2203683, * MN150S-O,
2203684, * MN150S-Y,
2203686, * MN150S-P,
2202823 or * 2SC5200-O or
2202822 * 2SC5200-R,Transistor
Q6060~Q6062 2202813 or * 2SA1943-O or
2202812 * 2SA1943-R,Transistor
Q6063~Q6065 2203693, * MP150S-O,
2203694, * MP150S-Y,
2203696, * MP150S-P,
2202813 or * 2SA1943-O or
2202812 * 2SA1943-R,Transistor
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (h
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<B>: Black model only
<G>: Golden model only
<S>: Silver model only
<D>: 120V model only
<P>: European model only
<T>: 230-240 model only
<K>: Korean model only
<A>: Australian model only
<R>: Chinese model only
<O>: Other models except
120V model
TX-SR700/E
EXPLODED VIEW-PARTS LIST 1
TX-SR700/E
Page 6
