Onkyo TX-SR800

CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<B>: Black model only
<G>: Golden model only
<D>: 120V model only
<O>: Except 120V model
<T>: Worldwide model only
<GT>: 220-230 V model only
<A>: Australian model only
<R>: Chinese model only
REF NO. PART NO. DESCRIPTION
1 27111301 Front bracket <B>
27111303 Front bracket <G>
2 27141787 Retainer HP
3 838430088 3TTB+8B(BC), Self-tapping screw
4 838130088 3TTB+8B, Self-tapping screw
5 27215364 Decorative frame <B>
27215365 Decorative frame <G>
7 28191942B Clear plate <B>
28191943A Clear plate <G>
8 28325964A Knob CL <B>
28325964A Knob CL <G>
9 28198778
82143010
Facet
3P+10FN(BC),Pan head
12 28325965 Knob, tuning
13 28330142 Cap, tuning
16 28135244 Badge <B>
28135245 Badge <G>
28 28325898 Knob, volume <B>
28325900 Knob, volume <G>
29 28325499A Knob, power <G>
28325497A Knob, power <B>
30 880016 P3035B, Plastic rivet
31 27255004 CS-1U, Clip
33 27100408-1A Chassis
34 27130870A Bracket, power transformer
35 27190965 Holder
36 27190693A KGLS-6RF, Holder
37 27190266 KGLS-12RF, Holder
38 27190164 KGLS-14S, Holder
39 830440089 4TTC+8C(BC), Self-tapping screw
41 28141484 Cushion
42 27191112 KGPS-6RF, Holder
43 27141797 Retainer, fan
44 27150470 Shield plate, fan
45 838450108 5TTB+10B(BC), Self-tapping screw
47 27150471 Shield plate
49 27150474 Shield plate, wire
52 27160489A Heat sink
53 801606 3SMH10W.SW+15B(CU), Special screw
54 27141681 Retainer, PC board
55 27141798 Retainer R, heat sink
56 27141799 Retainer L, heat sink
57 27130869 Bracket, heat sink
58 27130745 Bracket
61 838430107 3TTB+10S(BC), Self-tapping screw
62 28184817-1 Top cover <B>
28184819-1 Top cover <G>
63 29362772 Label, cover
64 838440089 4TTB+8C(BC), Self-tapping screw <B>
838240089 4TTB+8C(NI), Self-tapping screw <G>
65 838430088 3TTB+8B(BC), Self-tapping screw <B>
838930088 3TTB+8B(UN), Self-tapping screw <G>
66 29363226 Label, display
67 27175319B Leg
68 28141494 Cushion
69 831430088 3TTW+8B(BC), Self-tapping screw
70 27123035 Rear panel <D>
27123036 Rear panel <T>
27123037 Rear panel <A>
27123038 Rear panel <R>
27123039 Rear panel <GT>
71 838430088 3TTB+8B(BC), Self-tapping screw
72 87643010 W3*10F(BC), Flat washer
73 838930088 3TTB+8B(UN), Self-tapping screw
74 838430068 3TTB+6B(BC), Self-tapping screw
75 27191130 ! Holder, outlet <R>
77 27300750 ! Bushing, cord <D/A/GT>
27301927 ! Bushing, cord <T/R>
78 28141467 Cushion
REF NO. PART NO. DESCRIPTION
81 27212444 Front panel <B> <D/A>
27212445 Front panel <B> <T>
27212446 Front panel <G> <T/R/GT>
27212457 Front panel <G> <A>
83 27190470 KGLS-18S, Holder
86 260208 Binder
87 260258 Binder
97 223025 AC262, Isolated sheet
E821 24502310 D09T-24PG10(EX), Fan
F6901,F6902 252199 ! 10A-UL, Fuse <D>
252100 ! 10A-EAK, Fuse <OT>
F901 252199 ! 10A-UL, Fuse <D/T/R>
F902 252077, ! 4A-SE-EAK,
252243 or ! 4A-SE-TL250V or
252277 ! 4A-SE-TL250V, Fuse <O>
F903 252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <O>
F9501,F9502 252160 or ! 2.5A-UL/T-237 or
252254 ! 2.5A-T/UL-ST2, Fuse <D>
252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <O>
F9501A 29363313 T2.5AL1.6AL250V, Label, fuse <O>
F9503,F9504 252158 or ! 1.6A-UL/T-237 or
252252 ! 1.6A-T/UL-ST2, Fuse <D>
252073, ! 1.6A-SE-EAK,
252239 or ! 1.6A-SE-TL250V or
252273 ! 1.6A-SE-TL250V, Fuse <O>
P1010 2047151012 NCFC7-151012, Flexible cable
P2901 2047191012 NCFC7-191012, Flexible cable
P6009 27141825 Retainer, bus
P6205 27141826 Retainer, bus
P7201 2047312512 NCFC7-312512, Flexible cable
P7701 2047051012 NCFC7-051012,Flexible cable
P901 253347VOL ! AS-UC-2, Power supply cord <D>
253348VOL ! AS-CEE-3, Power supply cord <T>
253349VOL ! AS-CCEE, Power supply cord <R>
253307VOL o
r
! AS-SAA or
253197HIT ! AS-SAA, Power supply cord <A>
253306VOL o
r
!AS-CEE-2 or
253233KAW ! AS-CEE-2, Power supply cord <GT>
Q6050~Q6056 2202822 * 2SC5200-R, Transistor
2202823 or * 2SC5200-O or
Q6060~Q6066 2202812 * 2SA1943-R, Transistor
2202813 or * 2SA1943-O or
Q9422A 223026 Isolated sheet
Q9422B 223032 TO-66(1), Isolated washer
T901 2301653 ! NPT-1454D, Power transformer <D>
2301654 ! NPT-1454P, Power transformer <P/A>
2301655 ! NPT-1454DG, Power transformer <T/R/GT>
U1 1A956587-1K NADG-7687-1K, DSP circuit PC board
ass'y <D/A>
1A956587-1L NADG-7687-1L, DSP circuit PC board
ass'y <T/R/GT>
U6 1A956590-1K NAAF-7690-1K, F/C ch. driver circuit PC
board ass'y <D>
1A956590-1L NAAF-7690-1L, F/C ch. driver circuit PC
board ass'y <T>
1A956590-1M NAAF-7690-1M, F/C ch. driver circuit PC
board ass'y <A>
1A956590-1N NAAF-7690-1N, F/C ch. driver circuit PC
board ass'y <R>
1A956590-1P NAAF-7690-1P, F/C ch. driver circuit PC
board ass'y <GT>
TX-SR800
EXPLODED VIEW-PARTS LIST
