Onkyo TX-SR800

NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<B>: Black model only
<G>: Golden model only
<D>: 120V model only
<O>: Except 120V model
<T>: Worldwide model only
<GT>: 220-230 V model only
<A>: Australian model only
<R>: Chinese model only
REF NO. PART NO. DESCRIPTION
U38 1A956531-1K NAVD-7731-1D, Component video PC
board ass'y <D>
1A956531-1L NAVD-7731-1L, Component video PC
board ass'y <T/R/GT>
1A956531-1P NAVD-7731-1P, Component video PC
board ass'y <A>
U41 1A956524-1K NAETC-7724-1K, PC board for holder <D>
1A956524-1L NAETC-7724-1L, PC board for holder <T/R/GT>
1A956524-1M NAETC-7724-1M, PC board for holder <A>
U42 1A956523-1K NAETC-7723-1K, PC board for holder <D>
1A956523-1L NAETC-7723-1L, PC board for holder <T/R/GT>
1A956523-1M NAETC-7723-1M, PC board for holder <A>
U44 1A956546-1A NADIS-7746-1A, Display circuit PC
board ass'y <D>
1A956546-1B NADIS-7746-1B, Display circuit PC
board ass'y <B><A>
1A956546-1C NADIS-7746-1C, Display circuit PC
board ass'y <G><A/GT>
1A956546-1D NADIS-7746-1D, Display circuit PC
board ass'y <B><T>
1A956546-1E NADIS-7746-1E, Display circuit PC
board ass'y <G><T/R>
U45 1A956548-1A NAETC-7748-1A, Volume PC board ass'y
<D>
1A956548-1B NAETC-7748-1B, Volume PC board ass'y
<B><A>
1A956548-1C NAETC-7748-1C, Volume PC board ass'y
<G><A/GT>
1A956548-1D NAETC-7748-1D, Volume PC board ass'y
<B><T>
1A956548-1E NAETC-7748-1E, Volume PC board ass'y
<G><T/R>
U39 1A956533-1K NAETC-7733-1K, RI terminal PC
board ass'y <D>
1A956533-1L NAETC-7733-1L, RI terminal PC
board ass'y <T/R/GT>
1A956533-1P NAETC-7733-1P, RI terminal PC
board ass'y <A>
U40 1A956534-1K NAETC-7734-1K, Connector PC
board ass'y <D>
1A956534-1L NAETC-7733-1L, Connector PC
board ass'y <T/R/GT>
1A956534-1P NAETC-7733-1P, Connector PC
board ass'y <A>
U46 1A956549-1A NAETC-7749-1A, Headphone terminal
PC board ass'y <D>
1A956549-1B NAETC-7749-1B, Headphone terminal
PC board ass'y <B><A>
1A956549-1C NAETC-7749-1C, Headphone terminal
PC board ass'y <G><A/GT>
1A956549-1D NAETC-7749-1D, Headphone terminal
PC board ass'y <B><T>
1A956549-1E NAETC-7749-1E, Headphone terminal
PC board ass'y <G><T/R>
U47 1A956521-1K NAETC-7721-1K, Front video PC
board ass'y <D>
1A956521-1L NAETC-7721-1L, Front video PC
board ass'y <T/R/GT>
1A956521-1M NAETC-7721-1M, Front video PC
board ass'y <A>
U48 1A956522-1K NAETC-7722-1K, Front opto. input
PC board ass'y <D>
1A956522-1L NAETC-7722-1L, Front opto. input
PC board ass'y <T/R/GT>
1A956522-1M NAETC-7722-1M, Front opto. input
PC board ass'y <A>
U50 1A956547-1A NAETC-7747-1A, Standby switch PC
board ass'y <D>
1A956547-1B NAETC-7747-1B, Standby switch PC
board ass'y <B><A>
1A956547-1C NAETC-7747-1C, Standby switch PC
board ass'y <G><A/GT>
1A956547-1D NAETC-7747-1D, Standby switch PC
board ass'y <B><T>
1A956547-1E NAETC-7747-1E, Standby switch PC
board ass'y <G><T/R>
U51 240138A or ENG06501QR or
240134A TFCE1U114B, Tuner pack <D>
240139A or ENG07501QR or
240135 TFCE1E512A, Tuner pack <O>
REF NO. PART NO. DESCRIPTION
EXPLODED VIEW-PARTS LIST
