2 Hardware Setup
The sketch below illustrates the vital components of the OnStep control system. Note
that the following features and functions are optional and not provided by default:
Rotator and Focuser Control: These functionalities are not enabled and not
included.
Home Switches: The necessary wiring for home switches is not provided.
Limit Switches: While the features for limit switches are enabled, the actual limit
switches and necessary wiring are not included.
4
