No. Name Description Range Default
50 TMod Temperature modify/calibrate -9/+9 ºC 0
51 ATHi High temperature alarm limit used
for summer ventilation. Alarm 1 is
activated when temperature exceeds
option. Temp setting 72 deg C/ F will
auto convert
0-99 ºC
0-210 ºF
60
140
52 W/U Warm up delay disables alarms, seconds 0-255 60
53 BMM BACnet maximum MAC address when
polling for master
0-127 127
54 BDiag BACnet diagnostic display while
accessing this option. In format
XXXXYYZZ. Where YY is MAC
address (in hex) of the monitor that
just passed the token to the current
one. ZZ is the monitor to which the
token was passed to. Example 0305
would display on monitor with MAC
address 4
55 ATLo Low temperature alarm limit (alarm 3).
0=off
0C/ 32F
56 Net Enables display on home screen of all
monitor on CAN network. 1=0n
0/1 0
57 Ref-A To select scale and type of gas for
sensor A.
For model 6020: R507, R23, R134a,
R152a, R492a, R404a, R407a, R408a,
R410a, R500, R502, R507
For model 6013: R22, R21, R141b,
R142b, R401a, R402a, R408a, R409a,
R502a
For Model 6021: R134a, R125,
R404a, R410a, R407a, R407c, R407f,
R448a, R449a, R513a, R22, R123,
R507, R1234yf, R1234zf
select
from list
R507
R22
58 Ref-B As setting no. 57 but for sensor B
(bottom socket)
59 FltTx
Fault alarm transit message, CAN
network
0-255 0
4.4 List of Settings
