Optex VX-402 - Description and Operation

2.DESCRIPTION AND OPERATION
-3-
Pole Mount Bracket
M4 x 12
Plate
M4 x 6
Mounting Screw
T4 x 20
Te r minals
Pyro Electric Sensor
(Do not touch)
Speaker (VX-402REC only)
Plate Lock Screw
Lock Screw
Cover
LED Indicator
DIP Switch A
(Page 9)
Lens Holder
Lens
Cover
Area Masking Plate
(Page 8)
DIP Switch B
(Page 9)
Detection Length
Adjustment Switch
(Page 9)
Sensitivity Select
Switch (Page 9)
There are switches only for
VX-402REC in this portion (Page 6, 9)
