Product Specification
Demodulator
Waveform QPSK demodulation and FEC decoding in accordance with DVB
Symbol rate 2<Rs<40 Msps
Video-Decoder
Data rate up to 15 Mbits/s
Audio-Decoder
Decompression MPEG-2 Layer I and II
Outputs Stereo, Dual Mono, Joint Stereo, Mono
System
CPU Haier 2301E
Clock frequency 108 MHz
Flash memory 1 Mbyte
Video RAM 4 Mbyte
Graphic display 720*576 (PAL)
720*480 (NTSC)
LNB & Tuner input
Input frequency 950 … 2150 MHz
Digital signal Input level -65 … -25 dBm
LNB supply 13,0 ± 0,5V / 18,0 ± 0,7V / max. 400mA
Band switch control 22kHz (CPU control)
Connector Summary
TV Scart Output 1 * 20 Pin
RCA Output: CVBS, Audio L/R
LNB 1 * LNB input (F-Type)
1 * LNB output (F-Type, Loop Through)
RS-232 Bit Rate: 115200baud, Connector: 9-pin D-sub Male Type
Remote Control
Number of keys 33 (optional more)
Battery 2 * 1,5V AAA
Power Supply
Main Input Voltage 90~240V AC, 50/60Hz ± 5%
Power Consumption Nominal 5W (standby < 1W)
Physical Specification
Size (W x H x D) 205mm x 40mm x 300mm
Weight (Net) 0,625kg
