Front Panel
Funktion
1. The red LED
Lights up when the receiver has been standby on.
2. The green LED
Lights up when the receiver has been working.
3. The yellow LED
Lights up when the channel has been locked.
4. OK
Confirm it or list channels.
5. MENU
Display menu OSD.
6. CH+
Change channel up or scroll up through menu options.
7. CH-
Change channel down or scroll down through menu options.
8. STANDBY
Turns the receiver On/Off.
9. IR-Sensor
Receive the remote control signals.
Funktion
1. LNB IN
CONNECT TO SATELLITE ANTENNA
2. LOOP OUT
CONNECT TO THE OTHER RECEIVER
3. A-L / A-R OUT
CONNECT AUDIO CHINCH R/L TO TV
4. VIDEO OUT
CONNECT VIDEO CHINCH TO TV
5. SCART OUT
CONNECT VIDEO TO TV USING TV SCART
6. POWER SUPPLY
AC PLUG
7. POWER SWITCH
POWER ON/OFF
