SPECIFICATIONS
DC INPUT
12V 1A
Design and Specifications are subject to change without notice.
TUNER & CHANNEL
RF INPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, FEMALE)
RF OUTPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, MALE (LOOPTHROUGH))
FREQUENCY RANGE:
174MHz~230MHz(VHF)
470MHz ~862MHz (UHF)
SIGNAL LEVEL:
-15 ~ -80 dbm
DECODER
Video decoder
Audio decoder
VIDEO FORMATS
MODULATION
VIDEO OUTPUT
INPUT RATE
MAX. 48Mbit/s
4:3/,16:9 SWITCHABLE
HDMI, CVBS, RGB
QPSK,16QAM,64QAM, 256QAM
CONNECTION
ANTENNA INPUTx1, RF OUTPUT x1
POWER SUPPLY
MPEG-2 MP@HL, AVC/H.264 HP @L4.1
MPEG-4 ASP SUPPORTED
HEVC/H.265 MP@L4.1
MPEG-1 Layer 1,2/PCM/HE-AAC V1.0
ICE958 SPDIF/Dolby D+ and Dolby D
NOTE:
HDMI OUTPUT x1
USB slot x1
TO TV x1
COAXIAL x1
ETHERNET x1
TUNER
HDMI
DATA PORT
SCART
SPDIF
LAN
WIFI
Operating Frequencies:
2.4G~2.4835Ghz
IEEE Standards:
IEEE 802.11b/g/n
POWER CONSUMPTION
<=7W
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
