Version 3.1.8 dated 2015-1-27 Page 15Original operating instructions
BF20V US
2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data.
2.1 Power Suply
Motor 1.2 HP, 115V, 1 Ph, 60 Hz
2.2 Drilling-milling capacity
Drilling capacity 14 mm/ 0.5" max. diam.
Milling capacity of end-mill cutter 16 mm/ 0.6" max. diam.
Milling capacity of inserted tooth cutter 40 mm/ 1.6" max. diam.
Swing 370 mm/ 14.6"
2.3 Spindle holding fixture
Spindle holding fixture MT2 w/ 3/8"-16 draw bar
Quill travel 50 mm/ 2.0"
2.4 Mill drill head
Swivelling + / - 90°
Reduction stages 2
Z-axis travel 280 mm/ 11"
2.5 Cross table
Table length 500 mm/ 19.7"
Table width 180 mm/ 7.0"
Y-axis travel 175 mm/ 6.9"
X-axis travel 280 mm/ 11.0"
T - slot 1/2" slots, theree
2.6 Dimensions
Height 935 mm/ 36.8"
Depth 565 mm/22.3"
Width 745 mm/ 29.3"
Total weight 440 Kg./ 227 lbs
2.7 Work area
Height 2,000 mm/ 78.7"
Depth 2,200 mm/ 86.6"
Width 1500 mm/ 59.0"
2.8 Speeds
Reduction stage slow 90 - 1,500 RPM
